A 20000 gallon heavy duty vertical tank for liquids up to 1.9 specific gravity
The Norwesco 20000 gallon blue heavy duty vertical tank, part number 43827, is a high density linear polyethylene storage tank 165 inches in diameter and 242 inches tall, weighing 5015 lb empty. It is one of the largest single polyethylene tanks made, and the heavy duty wall is built for liquids up to 1.9 specific gravity, which is 15.87 lb per gallon: dense fertilizer solutions, brine, the coagulants and acids a water plant takes by the tanker load. It comes with a 3 inch polypropylene female NPT bulkhead fitting as the outlet and a 22 inch threaded vented manway on top. The service limit is 120 F and Norwesco backs it with a 3 year limited warranty with full replacement. Full of water the tank holds 166800 lb; at the full 1.9 rating the contents weigh 316920 lb, and everything about the install starts from that number.
Engineer on the job? Request a written quote with the spec attached, or get freight to your ZIP and add it to your cart above; 866-418-1777 answers the technical questions.
Where this tank goes
A bulk terminal, a fertilizer plant, a municipal treatment works, a mine or a processor that would rather take one transport load into one tank than split it across three. The specific gravity rating is the one number that decides between this tank and the standard versions linked below: check the liquid's density at its working concentration and temperature, and if it is over 1.5 you are on this page for a reason. Polyethylene handles water, most fertilizers and many common chemicals; confirm anything aggressive against the material before you order. Light blue cuts the light reaching the contents, which slows algae in stored water. Our 20000 gallon vertical tank buyer's guide covers the whole size class, and for a fire reserve read fire water reservoir design for rural sites. If your project needs certification paperwork for this model, ask us before you order and we will tell you what Norwesco provides.
Openings, fittings and what to check before you buy
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the sidewall. On a tank this tall the head at the outlet is high; the valve and the first length of pipe need their own support and a rating to match, and an expansion joint between the tank and rigid pipe is normal practice because polyethylene moves as it fills.
- Manway. A 22 inch threaded vented manway on top. At 242 inches up it needs a fixed ladder or platform; plan that with the pad. The vent must stay clear; a tank this size pulls hard when it drains.
- The pad. A 165 inch circle carrying up to 316920 lb is engineered work: designed, specified, poured to the specification and checked before the tank goes on it. Our note on concrete pad sizing for above ground polyethylene tanks sets out the framework your engineer will work within.
- Headspace. Heavy duty tanks holding reactive chemicals fail from the vapor side first. Read why premature failures start in the headspace before you set the inspection schedule.
- Drawing. Norwesco's drawing for this tank is linked on this page under Technical Drawing, with the outlet height and the manway position.
Same tank, other ratings and colours
Same heavy duty tank in black, for light sensitive liquids: the 20000 gallon black heavy duty vertical tank. If the liquid is water or anything else at or under 1.5 specific gravity, the standard wall saves weight: the 20000 gallon white standard tank or the 20000 gallon black standard tank. One heavy duty size down, in a taller and narrower shape: the 15500 gallon black heavy duty tank. The colour and rating pills above the price switch between the versions of this tank, and the tank sizing calculator and tank sizing guide help if the volume is still open.
Shipping and receiving
The tank ships on its side as an oversize load, 242 by 165 by 165 inches and 5015 lb, from the nearest of Norwesco's Albertville, Alabama; St. Bonifacius, Minnesota and Washington Court House, Ohio plants. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. Unloading and standing the tank up are yours: a crane with slings and a tag line, never forks against the shell, and clear air above the pad for the lift. At the tailgate, check the part number against 43827, walk the shell for transit damage, and fill with water the first time so any problem shows up with something harmless inside.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Albertville, AL; St. Bonifacius, MN; Washington Court House, OH. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 43827.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 20000 Gallon Blue Heavy Duty Vertical Liquid Storage Tank video (74 seconds) with dimensions, fittings and shipping notes.
