15500 Gallon Vertical Liquid Storage Tank

Where a twenty foot tank goes

This is the fifteen thousand class tank for a site that is tight on ground and has nothing overhead: a slot in a tank farm, a strip beside a plant building, a yard where the pad footprint is fixed. Twenty feet of shell brings rules of its own. The pad is level, continuous and carries the whole 141 inch floor, and full of water that floor carries 129270 lb of liquid plus the tank, so design it with our concrete pad sizing guide. The manway is a fixed ladder or platform job, wind loading and tie-down are worth a conversation with your engineer, and everything overhead needs checking before the truck comes. For a fire reserve, the fire water reservoir design guide covers sizing discipline and freeze protection; for rainwater and reuse, the industrial water reuse topology guide shows where a tank this size sits in the train. The complete buyers guide to this tank goes deeper, and the tank sizing calculator and tank sizing guide settle the volume first.

Openings and fittings

1. Outlet. A 3 inch 316 stainless steel female NPT bolted fitting, factory installed low in the side wall. With twenty feet of liquid above it, the bolted stainless fitting is the hardware for the job. Your 3 inch valve threads straight in. Support the valve and the first run of pipe on their own so the fitting carries liquid, not hardware.
2. Manway. A 22 inch threaded vented manway on top, 244 inches up: fill point, vent and a wide opening for a pump drop, a float or a cleaning crew's gear.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and manway position for your layout.
4. Liquid. Water and most liquid fertilizers sit inside the 1.5 specific gravity rating. For heavier liquids Norwesco makes a 1.9 rated version of this shell, listed below. For anything other than water or a common fertilizer, tell us what it is so we can check it against both the polyethylene and the stainless fitting.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 15500 gallon black vertical tank 43983. Same shell rated for liquids up to 1.9 specific gravity: the 15500 gallon blue heavy duty vertical tank 43943 and the 15500 gallon black heavy duty vertical tank 43943B. Five hundred gallons less on a much wider, much shorter shell: the 15000 gallon black vertical tank 43821B. The next size up, wider and a shade shorter: the 20000 gallon black heavy duty vertical tank 44334. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from Norwesco's Hanford, California plant, 244 by 141 by 141 inches lying down on the truck and 4114 lb. It travels on an open trailer and needs a forklift or a loader with forks rated for the weight, a crew with straps, and room to stand a twenty foot tank up beside its pad; for a tank this tall, many sites bring in a crane or a telehandler for the lift. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 43941 on the bill of lading, look over the shell and the stainless fitting for transit damage before you sign, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
