Snyder Industries 1000 Gallon Plastic Vertical Double Wall Liquid Chemical Storage Tank in White

Containment that ships on the truck

A single wall tank of regulated chemical needs a berm sized to its volume, and a berm is concrete, a sump, a drain valve that must stay closed, and a rain problem. A double wall tank carries its containment inside the outer shell, so the 81 inch footprint is the whole footprint and the tank can stand inside an occupied building where a spill must never reach a floor drain. The SPCC 40 CFR 112 compliance walkthrough covers where a double wall tank satisfies a spill plan on its own. The list below is the resin's rated chemistry; check the liquid at its concentration in the chemical compatibility database, because weight rating and chemical resistance are separate properties. The 1,000 gallon vertical tank buyers guide compares the single wall tanks at this volume, which is the right comparison only if a berm is already in place. The tank sizing calculator sizes the volume to feed rate and delivery interval.

Snyder double wall tanks near 1,000 gallons

The N42 is the cross-linked polyethylene version at the same weight, the wall for hypochlorite, sulfuric acid at strength and warm liquids; the N48 is another resin option 25 pounds lighter. The 5990902N30 is the 750 gallon double wall on a 73 inch base, and the 5470000N48 is the tall answer, 1,100 gallons at 104 inches on a 76 inch base, for the room with height and no floor.

Still deciding between these? Freight to your ZIP often settles it; the wider tanks ship differently. Or call 866-418-1777 and we will walk the table with you.

Openings and the interstice

• Access: 18 inch threaded, vented manway on the primary tank, at chest height; vent outside on anything that fumes, fill through a dip tube.
• Outlet: through the primary and secondary walls together, with the transition supported off the floor; specify the fitting for the chemical when ordering.
• Service limit: 120 F / 48 C.

A double wall tank has two levels to watch: the liquid in the primary, with a sender chosen for the chemical, and anything that appears in the interstitial space, which is the leak alarm; a simple float or conductivity switch in the interstice does that job. The space is inspected on a schedule, a look into the port each shift and a logged check each week, and anything found there is a primary leak that takes the tank out of service the same day. Nothing is stacked against the outer shell, nothing is bolted through it, and the interstice is never used to store anything. The tank sizing guide covers the reserve to carry between deliveries.

Turnover and changeover

A thousand gallons is four totes, on a schedule set by the feed rate; size the schedule so the tank turns over before the chemical degrades, and for hypochlorite that means small lots often. The low shape earns its keep at changeover: the manway is at chest height, the floor is a hand's reach through it, and a wash-down wand cleans the interior without anyone leaning over an opening. Drain, rinse, drain again, and let it dry before the new fill. Mount the dosing pump below the outlet so it primes by gravity, and give the vent a line routed away from the pump's electrical gear.

Installing a double wall tank

The pad is an 81 inch circle in full contact: a slab or a compacted base, level, that will not settle under 15,846 pounds. Leave a clear side for the outlet, the valve and the dosing pump, and leave the interstitial inspection port where an operator can see into it without moving anything. Keep a walkway around the outer shell so nothing gets leaned against it, and route the vent line to the outside before the first chemical arrives, because the off-gas from an open tank is what corrodes the electrical gear in a feed room.

Jobs it is bought for

Hypochlorite, caustic and coagulant storage at water systems that cannot build a berm, chemical storage inside occupied buildings, and any regulated liquid at a site an inspector visits. One chemical per tank, labeled, manway closed against vapor loss.

What the carrier needs from you

At 81 inches across the 5990102N45 ships as LTL freight (NMFC 156600-03), palletized, at a class rate the freight cost estimator shows for your ZIP; the listed price is before freight. A liftgate and a pallet jack handle 525 pounds. Water-test the primary to the manway, confirm the interstice stays dry through the hold, then drain and dry before the chemical delivery. Note the pad height and the outlet height on the site plan while the tape is out; the next pipe run will need both.

Chemical service ratings

The resin is rated for the liquids below at the concentrations shown; the fitting and gasket called out are the ones to order with the tank. Verify the exact service on the linked page or in the chemical compatibility database before ordering.
