200 gallons under a four foot ceiling, ASTM certified
The Snyder 1540000N45 is a squat vertical liquid storage tank: 200 gallons of white polyethylene in a shell 40 inches across and 48 inches tall, weighing 63 pounds. It carries a 1.9 specific gravity wall, rated for 3,169 pounds of contents against 1,668 for water, it is sold with ASTM certification for jobs that need the paper, and at 48 inches it goes under a bench, a mezzanine or a shelf where the taller 200 gallon tanks will not. A 6 inch threaded lid on top and a 3 year warranty.
Spec sheet in hand? Call 866-418-1777 and read us the liquid and the pad; or get freight to your ZIP and add it to your cart above.
Low, stable and certified
A tank barely taller than it is wide cannot tip and keeps a pump suction flooded to the last few inches; the cost is a 40 inch circle of floor in full contact with a level base, carrying up to 3,169 pounds at the rating, which a paver pad or a slab supports. The certification is against ASTM D1998, the standard rotationally molded polyethylene tanks are specified to, and the way a tank meets it is in the wall; the HDPE tank wall thickness guide explains the D1998 sizing logic and why the vapor headspace is where tanks fail first. The 200 gallon vertical tank buyers guide compares the shapes in this class across makers; the tank sizing calculator sizes a day tank to the pump's rate and the refill schedule, and the tank sizing guide covers the reserve to carry.
Squat and tall at 200 gallons
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1540000N45 (this tank, ASTM certified) | 200 | 40 x 48 in | 63 lb |
| 1540300N45 (heavy wall, ASTM certified) | 200 | 36 x 59 in | 110 lb |
| 1008000C26 | 200 | 36 x 53 in | 65 lb |
| 1540400N42 (XLPE) | 190 | 42 x 47 in | 60 lb |
| 1012900C26 | 210 | 36 x 55 in | 65 lb |
The 1540300N45 is the same 200 gallons in a taller, much heavier shell for the site that wants the thickest wall. The 1008000C26 and 1012900C26 are the general doorway tanks on a 36 inch base at 53 and 55 inches, and the 1540400N42 is the cross-linked squat tank for oxidizers, an inch shorter than this one on a base 2 inches wider.
Not sure which one? Tell us the liquid, the site and the ceiling height at 866-418-1777, or request a written quote with freight to your ZIP.
What is fitted
- Access: 6 inch threaded lid; filled by hose or tote pump, not poured.
- Outlet: name the chemical when ordering so the bulkhead fitting matches it; a flexible transition to the pump suction and a valve supported off the floor.
- Service limit: 120 F / 48 C.
- Listing: ASTM certification.
A 48 inch white tank shows its level in daylight, and a float switch for low level is usually enough in a pump room. The dosing pump sits below the outlet so it primes by gravity, and route the vent outside on anything that fumes. Lid closed against vapor loss; tank out of the sun for a light-sensitive chemical.
Applications
Under-bench day tanks in a plant lab, hypochlorite and caustic feed at small water systems, acid and inhibitor feed at a cooling tower, brine for a softener, and a reagent tank on a pilot skid where the certification has to be on file. One chemical per tank, labeled, refilled on a schedule the chemistry tolerates, and cleaned in minutes through the lid with a wand at changeover.
On the truck
The 1540000N45 ships palletized as LTL freight (NMFC 156600-02) at a class rate; the freight cost estimator quotes it to your ZIP, and what is listed here is the price before freight. One person carries 63 pounds. Water-fill it once to the lid, check the outlet fitting, and keep the certification paperwork with the project file. Mark the vent and the outlet on the outside of the shell so nobody caps the wrong one in the dark.
Freight and documents
Ships from: Lincoln, NE. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1540000N45.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
