Snyder Industries 2000 Gallon ASTM Black Captor Double Wall Tank

The duty a black two thousand is bought for

The duty comes first, and this one is bulk chemical storage on a site that keeps the product out of the light. Water and wastewater treatment works, package plants and lift stations, irrigation and agricultural chemical stores, mining and minerals operations, vehicle wash and laundry sites, and industrial process lines all buy two thousand contained gallons for the same reason: the volume is enough to change the bulk chemical cost per gallon and the delivery frequency, and it is small enough to place beside the equipment that uses it. A black wall keeps daylight out of what is inside, which is the practical difference between this listing and the opaque white one that shares its shell, and it matters wherever the vessel stands in a lit room or out in a yard. The containment job is the ordinary one and it is worth stating plainly: this tank goes where a release would reach a drain, a sump or the ground, where a bund is not going to be built, and where the site wants one item with one footprint rather than a tank plus a structure. What it asks for is a base designed against the loaded number. The sheet gives 16,680 pounds for the water alone at 8.34 pounds per gallon, and 31,692 pounds of max contents at the 1.9 rating; the 900 pounds on the delivery note is only what the forklift has to handle. Flat, continuous and level under the whole 102 inch footprint, with no packing at a corner. The shape helps everywhere else. At 103 inches on a 102 inch circle this is very nearly as wide as it is tall, which is a stable proportion outdoors, an easy one to get under a roof, and a reachable one when the manway has to be opened. Settle two sizing questions before ordering. The usable volume and the real headspace are not the nameplate figure, and the Captor double wall freeboard sizing guide works that through on thermal expansion, chemistry and density. Then size against your own consumption and delivery quantity in the tank sizing calculator, with the freeboard discipline from the tank sizing guide.

The same 103 inch shell in three names

Four part numbers sit on this 102 by 102 by 103 inch shell. Three are listed at 900 pounds and one, spelled with the SII prefix on the sheet, at 1,180; we print the weights and the spellings exactly as they are given and explain neither, because nothing on the sheet explains them. What distinguishes this row is on its own line: high density linear polyethylene, black, a service limit of 120 F / 48 C, and a specific gravity rating of 1.9 carrying 31,692 pounds of max contents. Check that rating against the liquid you are actually storing, because it is a per-listing figure and it is the number that rules a part number in or out. Where a drawing, a spares list or an installed tank already names one of these part numbers, order that one and we will confirm the published figures against it rather than substituting a shellmate. The two rows in other sizes are a shape decision rather than a volume one. 5490000N48 holds 1,550 gallons on a 76 inch plan at 136 inches and 780 pounds: it gives back a great deal of floor and takes it in height, and it puts the manway well above head height. 5580000N30 holds 2,500 gallons at 122 inches on this same 102 inch circle at 1,100 pounds, so it costs height and nothing else. Decide which constraint is the hard one at your site. If the floor is committed, the narrow tall tank is the answer and the access has to be designed for it. If the roof is the limit, stay wide and low, and this row is the one that sits comfortably under most of them.

Neighboring size a better fit? Every row links to its own page; freight to your ZIP is quoted on each, or call 866-418-1777.

Suction line, strainer and low level protection

• The pump path: the outlet field reads "1 Manway / Lid", an opening and not a pipe size, and this sheet publishes no inlet, no thread, no flange and no valve. Nothing beyond that is claimed. The working arrangement with one top opening is a suction line and strainer dropped through the manway to a pump on the ground beside the tank; tell us the duty, the flow and the line size and we will confirm what this part number carries before the pipe is run.
• Suction: keep the line short and generously sized and keep it full. A pump drawing from a wide, low tank has an easier time than one on a tall column, which is a quiet advantage of this shape and worth not spoiling with a long horizontal run.
• Prime: where the pump must stand above the working level, fit a real priming arrangement rather than trusting a foot valve to hold between shifts.
• Low level protection: set the strainer clear of the bottom so the settled inch is not the first thing drawn, and cut the pump out on low level. On a store that is emptied to the bottom of a delivery cycle, that switch pays for itself the first time a delivery is late.
• The fill opening: an 18 inch threaded vented manway is the only opening published, which makes it the delivery route, the inspection route and the cleaning route at once. Eighteen inches is enough to work a lance and to get a proper look inside.
• The vent: the manway is listed as vented, and that path protects the wall while a delivery pushes air out and while the pump draws the level down. Keep it clear and inspect it whenever the manway is opened.
• The space between the walls: no monitoring port, gauge or alarm is published on this sheet, so how that space is watched and recorded is specified separately and written down.
• Limits: 120 F / 48 C, a specific gravity rating of 1.9, and a 3 Year Warranty.

Tell us the product when you order and we will work the wetted parts back from it; on a contained vessel those parts are the only route a release has.

Outdoor chemical feed at a works yard

A black two thousand gallon contained tank is most often found where the vessel stands outdoors or in a bright building and the contents should not see daylight: a treatment chemical store in a works yard, a lift station or package plant compound, an agricultural or irrigation chemical point, a mine site water treatment package, a wash bay or laundry chemical store, and industrial process lines that take a delivery and draw it down over weeks. Keep the area around the base clear so the tank can be walked round and inspected, and keep the label legible; a bulk store nobody can read is a bulk store nobody checks. Where containment is being bought against a requirement rather than a preference, the Captor double wall compliance walkthrough goes through it in order and this page claims nothing about it. And where the wall itself is the question, the guide to wall thickness at the vapour saturated headspace explains where a polyethylene wall works hardest and why an inspection from the liquid side will not find it.

A 103 inch shell at 900 pounds, class 300

The plant is Lincoln, Nebraska and Nebraska the only ship-from state. Freight is LTL at class 300, the sheet gives no NMFC number, and the shipping size is listed at 102 by 102 by 103 inches at 900 pounds. Price the lane to your ZIP with the freight cost estimator; the listed price is before freight. This is a light load for its bulk, so what governs the delivery is the eight and a half foot width and the approach to the final position rather than the 900 pounds. Measure the gate and the turning room, book equipment that can take the tank under the base, and never lift by the manway. Set it on the finished, level surface where it will live before anything is connected to it. Fill with clean water, hold that 16,680 pound load, and read the manway seal, the base and the surface underneath in that order. Drain, dry, and open the space between the walls with a good light, then write the date on the shell. Put the part number on the maintenance record the same day; five years from now nobody will remember which of the four listings is standing in the yard, and the shell will not tell them. Once it is full and holding, leave it alone for a day before the plumbing goes on; a settled tank is a quiet one.
