The 300 gallon doorway tank with the 1.5 wall
The Snyder 32241 is a white high density linear polyethylene vertical liquid storage tank, 36 inches across and 72 inches tall, holding 300 gallons at 89 pounds. Its wall is rated for a specific gravity of 1.5, or 3,753 pounds of contents against 2,502 for water, so it holds brine, fertilizer solution and coagulant as delivered as well as water, and at 36 inches it goes through a standard door. A 2 inch outlet, a 20 inch manway, and it ships as standard LTL freight.
Is this the right 300 gallon tank? Call 866-418-1777 with the liquid, the site and the ceiling height, or get freight to your ZIP and add it to your cart above.
The heaviest doorway 300
Snyder makes several 300 gallon tanks that fit through a door; this is the one with the 1.5 wall, 89 pounds of resin against the water tank's 71, for a liquid half again as dense as water or a water tank that will live a long time outdoors. Twice as tall as it is wide, it is strapped to a wall, because 3,753 pounds on a 36 inch circle has a high center of gravity, and it stands on a slab or a paver pad in full contact. The 300 gallon vertical tank buyers guide compares the shapes at this volume across makers; the tank sizing calculator tells you whether 300 gallons covers the draw, and the tank sizing guide covers days of supply.
Snyder's 120 to 330 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32241 (this tank, 1.5 SG) | 300 | 36 x 72 in | 89 lb |
| WV21 (water) | 300 | 35 x 80 in | 71 lb |
| 1011200N52 (1.9 SG) | 300 | 35 x 82 in | 85 lb |
| 1008200N52 (squat, 1.9 SG) | 330 | 47 x 50 in | 108 lb |
| 1540200W94303 (3 inch outlet) | 120 | 32 x 41 in | 50 lb |
The WV21 is the water-rated doorway tank, 8 inches taller and 18 pounds lighter, for water and nothing heavier. The 1011200N52 carries the 1.9 chemical wall on a base an inch narrower, 10 inches taller, and the 1008200N52 lays 330 gallons of that same wall down to 50 inches on a 47 inch base. The 1540200W94303 is the 120 gallon batch tank with the 3 inch outlet.
Comparing across brands too? Call 866-418-1777; we carry Norwesco, Snyder, Chem-Tainer, Enduraplas and Bushman and will say which one fits, or price the freight first.
Bulkheads and lid
- Outlet: 2 inch, at the base; a flexible connector between the bulkhead and hard pipe, and the valve supported off the floor.
- Access: 20 inch manway, more than half the diameter of the tank.
- Service limit: 120 F / 48 C.
A 2 inch outlet on a 300 gallon tank feeds a small pressure pump without starving it, and six feet of head gives a hose a usable flow by gravity. A 20 inch manway on a 36 inch tank reaches the whole floor for cleaning, and the white wall means no sight tube: the level reads through the shell. Where it freezes, insulate or drain the outlet valve and the first length of pipe; the body takes ice from the top down without harm.
Day-to-day duty
Brine for a softener, fertilizer solution on a small farm, a well buffer in a utility room, a mixing or rinse tank in a shop, and emergency water in a garage. One liquid per tank, labeled.
From the plant to your site
The 32241 ships palletized as LTL freight (NMFC 156600) at a class rate; the freight cost estimator quotes it to your ZIP, and what is listed here is the price before freight. One person carries 89 pounds through the door. Strap it, fill it to the manway once, and check the outlet fitting before it goes to work. Write the fill date on the manway with a paint marker; it answers the first question anyone asks about a tank.
Freight and documents
Ships from: Albertville, AL; Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32241.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Snyder Industries 300 Gallon Plastic Vertical Liquid Storage Tank in White video (61 seconds) with dimensions, fittings and shipping notes.
