330 gallons, 50 inches tall, with a bolted outlet
The Snyder WG24R holds 330 gallons of water in a green polyethylene shell 47 inches across and 50 inches tall, weighing 65 pounds. It is the squat tank with the serious outlet: a 2 inch stainless steel bolted fitting instead of a threaded bulkhead, which is what you want when a pump suction or hard pipe hangs off a tank this small. Fifty inches goes under a deck, into a crawl space or into a pickup bed below the cab line, and green blocks light like black does. A 1-1/2 inch inlet, an 18 inch vented manway, a rating of 1.0 specific gravity for water and liquids no heavier, and a 3 year warranty.
Want it on your site? Get LTL freight to your ZIP, add it to your cart above, or call 866-418-1777 and a tank specialist will confirm the fit.
A low tank that gets plumbed
A 47 inch base under 50 inches of tank is stable without a strap, and full it carries 2,752 pounds, which a paver pad or compacted gravel in full contact with the floor supports; the concrete pad sizing guide covers a shared slab. The bolted outlet is the reason to choose it over the threaded tanks of the same size: a rigid suction line to a booster pump, a heavy ball valve or a manifold to a second tank all pull on the fitting, and a bolted flange carries that load without working the wall. The tank sizing calculator checks 330 gallons against the draw.
Snyder's 300 to 400 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| WG24R (this tank, green, bolted outlet) | 330 | 47 x 50 in | 65 lb |
| WB24R, black | 330 | 47 x 50 in | 70 lb |
| WG23, threaded outlet | 300 | 46 x 50 in | 75 lb |
| 32499, doorway | 300 | 36 x 72 in | 57 lb |
| 32505 | 400 | 40 x 80 in | 69 lb |
The WB24R is this tank in black, 5 pounds heavier. The WG23 is the same low shape with threaded fittings, 30 gallons less on a base 1 inch narrower, for the tank that is filled and left alone. The 36 and 40 inch tanks are the doorway shapes: the 32499 stands 72 inches and the 32505 stands 80 for 400 gallons, both for the closet with height and no floor.
Picked the 330 gallon tank? Add it to your cart above; freight is quoted to your ZIP before you pay anything.
Fittings and access
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting.
- Outlet: 2 inch polypropylene fitting with a stainless steel bolted flange, at the base; re-torque after the first full fill.
- Access: 18 inch threaded, vented manway, at waist height.
- Service limit: 120 F / 48 C.
Fifty inches of head is a gentle gravity feed, so this tank is usually paired with a pump, and the bolted outlet is where the pump's suction goes: mount the pump below the outlet so it primes by gravity, put a union and a check valve in the line, and support the pump off the floor. A sight tube off the outlet reads the level through the green wall.
Jobs it is bought for
Under-deck rain cisterns feeding a garden pump, crawl space well buffers, water for a cabin, a hauling tank in a pickup, and a cell of the small fire reserve the fire-water reservoir design guide describes. In multiples on a manifold, the storage stage of a small roof-water and condensate reuse system, per the industrial water reuse tank topology article; the tank sizing guide covers days of supply. On a truck, strap it through the manway ring and over the top to the bed anchors, never around the fitting, and drive it full or empty rather than half.
How it ships
The WG24R ships palletized as LTL freight (NMFC 156600-02) at a class rate; the freight cost estimator shows it for your ZIP, and the listed price is before freight. One person carries 65 pounds. Plumb the bolted outlet, fill to the manway once per the hydrostatic test methodology guide in miniature, and torque the flange bolts once more. Note the pad height and the outlet height on the site plan while the tape is out; the next pipe run will need both.
Freight and documents
Ships from: Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries WG24R.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Snyder Industries 330 Gallon Plastic Vertical Water Storage Tank in Green video (71 seconds) with dimensions, fittings and shipping notes.
