400 gallons on a 40 inch circle
The Snyder 32505 holds 400 gallons in a black polyethylene tank 40 inches across and 80 inches tall, 69 pounds empty. Forty inches is narrow enough for most doorways and utility rooms, and 69 pounds is light enough for one person to carry it there. A 20 inch threaded vented manway on top, a 1-1/2 inch polypropylene inlet and a 2 inch polypropylene outlet. Rated for a specific gravity of 1.0, water and lighter liquids only.
Two ways to buy. Add it to your cart above with freight quoted to your ZIP, or request a written quote for a job that needs paperwork.
Where a 40 by 80 inch tank goes
Inside: a basement or garage well reserve, a pressure system buffer, a pump house. Outside: a rain store beside a downspout, wash water at a shop, a small stock tank. Full, it weighs 3,336 pounds on a 40 inch circle, which is nothing on a slab and a point load on a wood floor; put it over a joist or on a small pad. Standing 80 inches, it wants a foot of clearance above the manway to open it, and it rides upright in a covered trailer or lying down in a pickup bed. The concrete pad sizing guide covers an outdoor base.
The sizes either side
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| WG24R, green | 330 | 47 x 50 in | 65 lb |
| 32505 (this tank) | 400 | 40 x 80 in | 69 lb |
| 32507, green | 400 | 40 x 80 in | 69 lb |
| 32615 | 400 | 40 x 80 in | 69 lb |
| 32511 | 500 | 48 x 76 in | 80 lb |
Three 400 gallon parts share this mold in different colors. The 500 gallon 32511 is 8 inches wider and 4 inches shorter for 100 more gallons and 11 more pounds; the 330 gallon WG24R is the crawlspace shape at 50 inches tall. Pick by the opening the tank has to pass and the ceiling it has to clear. The green 32507 is this exact tank for drinking water; the 32615 is a third color of the same mold.
Not sure which one? Tell us the liquid, the site and the ceiling height at 866-418-1777, or request a written quote with freight to your ZIP.
Plumbing it
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting on top, for a fill line or a float valve.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting at the base; valve, union, pump.
- Access: 20 inch threaded, vented manway. Indoors the vent still breathes; do not seal it.
- Service limit 120 F / 48 C.
Put the outlet valve where a hand reaches it without kneeling, and give the pump a union so it comes off without draining 400 gallons. On a pressure system the tank sits between the well pump and the pressure tank as a buffer, and the float valve on the inlet is what stops the well from running dry.
A sight tube on the outlet reads the level; for a pressure system the level gauge selection guide covers a float switch or sensor.
Four hundred gallons in use
A day of household water from a slow well, the makeup tank on a small reuse system laid out in the industrial water reuse topology guide, or a rain store with real capacity. It is not a fire reserve; the fire-water reservoir design guide explains what NFPA 22 actually asks for. Size it against your draw with the tank sizing calculator and the tank sizing guide.
Freight and first fill
LTL freight, NMFC 156600-02, 69 pounds crated at 40 by 40 by 80 inches; the freight cost estimator quotes your ZIP and the listed price is before freight. One person can carry it in. Fill it in stages the first time and check the outlet fitting under load, per the hydrostatic test methodology guide.
Freight and documents
Ships from: Merced, CA; Albertville, AL. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
