6,200 gallons in black at 1.9 specific gravity, under twelve feet on a ten foot base
The Snyder 8220000C34 is a black polyethylene vertical storage tank, 120 inches across and 140 inches tall, holding 6,200 gallons at 1,350 pounds. It is the tanker-and-a-bit tank for a roof that stops at twelve feet: 140 inches to the 18 inch threaded, vented manway leaves room for a platform where the 153 inch tanks do not, on the same ten foot circle, in a black wall that keeps light off the load. Its wall is rated for a specific gravity of 1.9, or 98,245 pounds of contents against 51,708 for water, for concentrated acid, ferric and the heavy brines at strength. A 3 inch polypropylene female NPT bulkhead outlet, a 3 year warranty, and freight at class 300 from Marked Tree, Arkansas.
Buying on a purchase order? Request a written quote and we will return it with freight to your ZIP; card buyers add the 6200 gallon tank to the cart above.
Thirteen inches shorter, and why that sells it
A plant sizes a chemical tank to its delivery, and a tanker is a tanker; the roof then decides which 6,000-and-some tank fits under it, and this one is the shortest on the ten foot base that still takes a full load with headspace. Full at the rating it puts 98,245 pounds on a 120 inch circle: an engineered slab under the whole floor, per the concrete pad sizing guide, with a berm sized to the tank, with the empty tank strapped against wind before the first fill. Black polyethylene absorbs the ultraviolet that ages a white wall and passes no light to the liquid; it runs warmer in the sun, so shade if the chemical must stay cool, and it hides the level, so a sender read at the ground is the gauge.Size it from the feed rate and how often the truck comes with the tank sizing calculator; the tank sizing guide covers the reserve to leave in the bottom and the freeboard a dense chemical needs for thermal expansion.
Grades on the 120 x 140 inch tank, and the 6,000 and 6,500 either side
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 8220000C34 (this tank, black, 1.9 SG) | 6,200 | 120 x 140 in | 1,350 lb |
| 8220000C37-BLACK (black) | 6,200 | 120 x 140 in | 1,350 lb |
| 8220000N40 | 6,200 | 120 x 140 in | 1,350 lb |
| 8220000N33 | 6,200 | 120 x 140 in | 1,174 lb |
| 7000000C34 (black) | 6,000 | 120 x 132 in | 1,050 lb |
| 7140000N33 | 6,500 | 120 x 153 in | 1,450 lb |
The C37-BLACK is the other black tank in this shell and the N40 the other chemical grade at this weight; the N33 is the lighter wall for water and liquids that do not need this one. The 7000000C34 is the black 6,000 eight inches lower still, and the 7140000N33 the 6,500 at 153 inches for a taller bay.
Ready to choose a row? Add the 6200 gallon tank to your cart above with freight quoted to your ZIP, or 866-418-1777 will confirm it against the site first.
The outlet and the vent line
- Outlet: 3 inch polypropylene female NPT bulkhead fitting, at the base; tell us the liquid when ordering and the fitting is matched to it, with a flanged transition, a flexible connector to hard pipe, and the valve supported off the pad in the material the chemical calls for.
- Access: 18 inch threaded, vented manway, 140 inches up; a platform with a rail for anyone who opens it. Dip tube to the floor on the fill, vent to the outside on anything that gives off gas, and a vent big enough for the delivery pump.
- Service limit: 120 F / 48 C.
Nearly twelve feet of liquid above a 3 inch outlet is a strong flooded suction, and the outlet drains a full tank in a working shift; the pump sits below the outlet and primes itself, and a low-level float stops it before the tank runs dry. Label the tank for the one chemical it holds, keep the lid closed against vapor loss, and when it opens, shine a light on the headspace wall, which ages before the wetted wall does. Where it freezes, insulate or trace the outlet valve and the first pipe run; the body takes ice from the top down without harm.
Chemical rooms with a twelve foot roof
Ferric and other dense coagulants at a water plant, caustic or acid at an industrial plant, brine at a food plant, and a fertilizer solution tank at a co-op. Water is inside its rating, but the fire-water reservoir design guide explains why a fire reserve is a different tank. The industrial water reuse tank topology article places a chemical tank this size in a reuse train.
From Marked Tree, as a permitted load
The 8220000C34 ships from Marked Tree, Arkansas as freight at class 300 as the sheet lists it; at 120 inches across and 140 long on the deck it is a permitted load, and the freight cost estimator prices the lane to your ZIP, with the listed price before freight. A crane stands 1,350 pounds up with straps under the body, never through the manway. Fill it with water to the manway once and hold it, watching the pad edge and the outlet fitting, then drain and dry before the chemical goes in, and the log takes the date and strength of every load after that. Leave room to walk all the way around it; the side of the tank nobody can see is the side that leaks.
Freight and documents
Ships from: Marked Tree, AR. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 8220000C34.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
