1350 Gallon Plastic Water Storage Tank

Where a tall 1350 goes

For a household on a well this is three or four days of normal use and a buffer that lets a slow well fill overnight. For a small holding it is the rain off a house and garage roof in a wet month, stock water with a margin, or the fill tank for a sprayer. The narrow footprint is the point: a 71 inch circle goes where the wide tanks of this volume do not, and the height gives the outlet a useful head when the tank gravity feeds a trough or a garden. At 88 inches the manway is above head height, so plan a step ladder for the yearly look inside and keep the float valve on the inlet line where it can be serviced from the ground. The footprint must sit on a flat, level, continuous base carrying 11,259 lb of water plus the tank: compacted gravel in a frame or a slab, and the concrete pad sizing guide explains the slab. A tall, narrow tank is the one that wants strapping while it stands empty in wind. If it is part of a rural fire supply, the fire water reservoir design guide explains how tanks this size combine into a reserve and how to protect them from freezing. For rainwater and grey water reuse, the water reuse storage guide is the place to start. Confirm the volume with the tank sizing calculator and the tank sizing guide.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting low in the wall. A 2 inch ball valve threads straight in; follow it with a union so the tank can be disconnected full. Support the valve and the first run of pipe on their own.
2. Inlet. A 1-1/2 inch polypropylene female NPT bulkhead fitting for the fill line from the well pump, a float valve or a roof drain.
3. Manway. A 16 inch threaded vented manway on top: fill from a hose, drop a float in, get an arm and a brush inside. It is also the vent.
4. Rating. 1.1 specific gravity, a maximum of 9.18 lb per gallon. Water and rainwater; liquid fertilizers are heavier and need a tank rated 1.5 or higher. Keep contents under 120 F.
5. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the fitting heights and the manway position.

Sizes and colours nearby

Same tank in dark green: the 1350 gallon dark green vertical water tank. One step down: the 1100 gallon dark green vertical water tank, a lower and wider shape. One step up: the 1500 gallon vertical water tank. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL, 71 by 71 by 88 inches at 204 lb, from Norwesco's Washougal, Washington plant. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. Two or three people take it off the truck. At the tailgate, check the part number against 40860 on the bill of lading, look the shell over for transit damage, stand it on the base, and run the water fill acceptance test before it carries anything else.

Questions before you order? Call 866-418-1777.
