2100 Gallon Vertical Liquid Storage Tank

For the space under a roof, a deck or a doorway header

Sixty-nine inches is five feet nine. This tank goes where other 2000 gallon class shells will not: under a low lean-to, inside a shipping container, beneath a mezzanine, or through a doorway standing up. The manway is at chest height, so filling, dipping and cleaning happen without a ladder. What you pay for the low wall is floor: the 102 inch base is eight and a half feet across, and it all has to be flat. The buyer's guide to this tank walks through the siting decision. If you have the height but not the floor, the taller 2100 gallon shells are linked below. If the volume is the open question, run your draw and refill interval through the tank sizing calculator and take the reserve margin from the tank sizing guide. If you may want more volume on a similar footprint later, the guides to Norwesco's low-profile 2500 gallon and 3000 gallon shells are worth a read now.

Openings, fittings and the pad

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. Your valve or camlock threads in; support the first length of pipe on its own.
2. Manway. A 16 inch threaded vented manway on top for filling, a float and cleaning. Leave the vent open.
3. The pad. The whole 102 inch circle needs continuous, level contact: a slab, a steel plate, or a compacted and screeded bed with a retained edge. Check it with an instrument across the full span, not just at the rim.
4. The liquid. Up to 1.5 specific gravity and 120 F. Heavier liquids need a 1.9 rated heavy duty tank, linked below.
5. Drawing. Norwesco's drawing is linked under Technical Drawing on this page and gives the outlet height and manway position.

Versions and sizes nearby

Same low-profile tank in black, for water standing in sun: the 2100 gallon black low-profile vertical tank. The taller, narrower 2100 gallon shell in black: the 2100 gallon black vertical tank. Heavy duty, rated to 1.9 specific gravity: the 2100 gallon black heavy duty tank. One step down: the 2000 gallon black vertical tank. One step up: the 2200 gallon vertical tank.

Shipping and receiving

The tank is an oversize LTL load, 102 by 102 by 69 inches on the trailer and 295 lb as shipped, from Norwesco's Lancaster, Ohio plant, which makes the Midwest and the East the short lanes. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote. An eight and a half foot shell needs a gate and a set-down spot to match; tell us if the yard is tight. At the tailgate, check the part number 41399 on the bill of lading, inspect the shell before signing, and fill it with water the first time.

Questions before you order? Call 866-418-1777.
