2,500 gallons at 84 inches: the low green tank
The Snyder 32565 holds 2,500 gallons of water in a green high density linear polyethylene shell 102 inches across and only 84 inches tall, weighing 400 pounds. It is the lowest 2,500 gallon shape Snyder makes, seven feet under the manway lid, for the barn bay, the lean-to and the equipment shed with a low header, and the green wall blocks light like black does while sitting quietly against a treeline. A 26 inch manway, threaded polypropylene fittings, and a rating of 1.0 specific gravity for water and liquids no heavier.
Want it on your site? Get LTL freight to your ZIP, add it to your cart above, or call 866-418-1777 and a tank specialist will confirm the fit.
An eight and a half foot circle of floor
Low means wide. The 32565 needs a 102 inch circle in full contact with a level pad, carrying 20,850 pounds when full; the concrete pad sizing guide gives the ACI 360R-10 method for a slab or a compacted base. In return the tank cannot tip, does not catch wind, and puts its 26 inch manway at a height a person reaches from a step. The tank sizing calculator confirms 2,500 gallons against the draw before the base is built.
The 2,500 gallon shapes, lowest to tallest
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32565 (this tank, green) | 2,500 | 102 x 84 in | 400 lb |
| 32559, black | 2,500 | 96 x 90 in | 343 lb |
| 32747 | 2,500 | 96 x 90 in | 300 lb |
| WG60, green, tall | 2,500 | 90 x 106 in | 415 lb |
| WG62, green, bolted outlet | 2,600 | 96 x 91 in | 427 lb |
Read the height column against your ceiling. The 96 inch tanks are 6 inches taller on a base 6 inches narrower; the WG60 is 22 inches taller on a 90 inch base, for the site with headroom and no floor. The WG62 adds 100 gallons and a stainless bolted outlet on the 96 inch base. Among the green tanks, the 32565 is the only one that goes under seven feet.
Picked the 2500 gallon tank? Add it to your cart above; freight is quoted to your ZIP before you pay anything.
What is fitted
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting at the base.
- Access: 26 inch threaded, vented manway.
- Service limit: 120 F / 48 C.
Only 84 inches of head sits over the outlet, so a gravity feed is gentle; plan a pump for anything beyond a trough. A green wall is opaque, and a sight tube off the outlet is the level gauge that works in every light.
Who buys this tank
Ranches and rural homes that want a 2,500 gallon fire reserve under a barn roof, sized under NFPA 22 per the fire-water reservoir design guide; irrigation and stock-water banks; and commercial sites that gang low tanks into a roof-water and condensate reuse train, per the industrial water reuse tank topology article. The tank sizing guide turns the gallons into days.
Freight for a wide, low tank
At 102 inches across the 32565 is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. A forklift with long forks lifts 400 pounds onto the pad. Fill in stages the first time with the base and both fittings under watch, per the hydrostatic test methodology guide. Once it is full and holding, leave it alone for a day before the plumbing goes on; a settled tank is a quiet one.
Freight and documents
Ships from: Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32565.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
