A 250 gallon white doorway water tank, the tall 25 inch wide version
The Norwesco 250 gallon doorway water tank, part number 45722, is a white polyethylene tank 59 inches long, 25 inches wide and 54 inches tall, weighing 103 lb empty. Norwesco makes the 250 gallon doorway tank in two shapes; this is the tall, narrow one. At 25 inches wide it passes a standard 3 foot door with room to spare, and the extra height is what keeps the footprint down. It comes with a 1-1/4 inch polypropylene female NPT bulkhead fitting as the outlet and a 16 inch threaded vented manway on top. The tank is rated for liquids up to 1.5 specific gravity; 250 gallons of water weighs 2085 lb. The resin is FDA compliant and UV stabilized, the service limit is 120 F, and Norwesco backs it with a 3 year warranty.
Is this the right 250? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with the door width and the ceiling height of the room.
Tall and narrow: where this version fits
The decision between the two 250 gallon doorway tanks is made overhead and across the floor. This one stands 54 inches, four and a half feet, and takes 59 by 25 inches of floor; the other version is wider and lower. Choose this one where floor space is the constraint and headroom is not: along a basement wall, in a utility room beside a water heater, in a garage bay, in a greenhouse aisle. Its 16 inch manway sits at a height a person opens without a step. Full of water it is 2085 lb standing on 59 by 25 inches, which a concrete floor carries without thought, while a raised wood floor wants a look underneath before the first fill. Outside, it needs a level pad in full contact with the whole base and the overflow led away from the pad edge. Our buyer's guide to this 25 by 54 inch tank goes through the common installs, and the fire water reservoir design guide covers using doorway tanks as a rural fire reserve.
What goes in it
Water is the normal load: an emergency reserve, a well holding tank, rainwater from a roof, wash water in a shop. The white wall lets you see the level through it in good light. The 1.5 specific gravity rating, a maximum of 12.52 lb per gallon, means it will also hold most liquid fertilizers and common solutions that polyethylene handles. Keep the contents under 120 F. For drinking water, keep the lid closed and the tank out of direct sun; light grows algae in standing water. To check that 250 gallons is the right amount, run your daily draw and refill interval through the tank sizing calculator and take the reserve from the tank sizing guide.
Openings and fittings
- Outlet. A 1-1/4 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. A valve, a hose adapter or a pump suction threads straight into it. Support the valve and the first length of pipe so the fitting carries water, not hardware.
- Manway. A 16 inch threaded vented manway on top: wide enough to fill from a hose, to drop a float switch in, and to get an arm and a brush inside to clean. The vent lets air in as the tank drains, so never seal it.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the exact outlet and manway positions.
Sizes nearby
The other 250 gallon doorway shape, 29 inches wide and 44 inches tall for a room with less headroom: the 250 gallon doorway tank, 29 by 44 inch body, and its companion 250 gallon doorway tank, part 41526. One size down: the 150 gallon doorway water tank. One size up: the 300 gallon doorway tank.
Shipping and receiving
The tank ships LTL on a pallet, 59 by 25 by 54 inches and 109 lb packed, from the nearest of Norwesco's plants in Hanford, California, Tooele, Utah and Washougal, Washington. Those three plants make this the version to look at first for a western buyer; the lane is short from any of them into the Central Valley, the Great Basin or the Pacific Northwest. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At 103 lb empty, two people walk it through the door. At the tailgate, check the part number 45722 against the bill of lading, look over the wall and the fitting for transit damage, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Hanford, CA; Tooele, UT; Washougal, WA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 45722.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 250 Gallon Doorway Water Tank - White (25" x 54") video (68 seconds) with dimensions, fittings and shipping notes.
Ready to order?
Add it to your cart at the top of this page, get LTL freight to your ZIP, request a written quote, or call 866-418-1777. The listed price is before freight.
3 Year Warranty
