2500 Gallon Plastic Vertical Liquid Storage Tank

Lincoln and Philippi: two plants, two lanes, and the one that wins is the one nearer you

Most tanks in this family come out of one plant. This one is listed at two, and on an oversize load that is worth more than a class point. Lincoln covers the plains and the upper Midwest, Iowa, Kansas, the Dakotas and the Front Range; Philippi covers the Appalachians and the Atlantic side, Ohio, Pennsylvania, Virginia and the Carolinas. Between them very little of the eastern two thirds of the country is a long haul, and since a 90 inch shell is wider than ordinary freight allows, the haul is a permitted move whose price is mostly miles. Tell us the ZIP and we will ship from the plant that makes the lane short. Once it lands, the installation is the pad and the strapping. A rotationally molded floor bears on the whole surface it touches and nothing else, so the 39615 pounds the sheet allows are carried on a 90 inch circle by whatever is under that floor; engineer the slab to the framework in the concrete pad sizing guide, level, in full contact, wider than the tank, and drain the overflow away from the edge. At 107 inches the shell is close to nine feet tall on a seven and a half foot base, which is tall enough to catch wind while it is empty at 560 pounds, so band or cable it before the first fill and check the tension after the first windy week and again after the first full summer. Then test the volume rather than trusting the number: 2500 gallons against your draw and refill interval in the tank sizing calculator, with the reserve and the freeboard from the tank sizing guide.

The 2500 gallon shell at 560 pounds, and the 450 pound moldings beside it

Four part numbers hold 2500 gallons in this exact shell and the sheet lists two empty weights for it, 560 pounds for this tank and 450 pounds for the other three, which is what the sheet says and what we print without explaining it. Among those three, two are black walls for a liquid that daylight degrades. The reason to buy this one is that it is the white wall whose sheet publishes both a service limit and a warranty term, and the one listed at two plants instead of one. Either side of the capacity, the choice is footprint against height: 5050000C26 keeps the 90 inch base and drops to 88 inches for a lower ceiling, giving up 500 gallons to do it, while 8390000C26 goes the other way and spreads 2650 gallons onto a 102 inch base at 97 inches, which is the buy when the roof is the hard limit and the floor is not. This page is the tall, narrow, white 2500 with the short lane.

Ready to choose a row? Add the 2500 gallon tank to your cart above with freight quoted to your ZIP, or 866-418-1777 will confirm it against the site first.

An 18 inch lid 107 inches up wants fixed access, not a leaned ladder

• Access: an 18 inch threaded vented manway 107 inches off the pad, close to nine feet. That is above comfortable reach, so the honest answer is fixed access with a rail, or a fill line brought down to a coupling at working level so nobody has to be on top of the tank to take a delivery. A leaned ladder against a round polyethylene wall is how people get hurt on tank farms.
• What goes in the top: bring the fill down a dip tube to the floor rather than letting a delivery drop nine feet onto the liquid, and keep the manway closed between deliveries so vapor stays in and rain stays out.
• Vent: keep it clear, and size it for the delivery pump rather than the transfer pump. A vent that cannot pass air as fast as a pump moves liquid is the most common way a polyethylene tank is damaged, in either direction.
• Headspace inspection: every time the lid is off, put a light on the band of wall just above the liquid line. It is the first place to change and the last place anyone looks.
• Outlet: a 2 inch polypropylene female NPT bulkhead fitting at the base, as the sheet lists it, with the liquid named at order so the fitting, gasket and bolting are matched to it.
• Service limit: 120 F / 48 C, with a 3 Year Warranty, as the sheet gives them.

Nine feet of standing liquid is genuine suction head and it is worth keeping. Set the pump below the outlet on its own base with a short, falling, straight run into the suction port and the column will prime it and hold it flooded down to the last inches; lift the pump level with the tank and the same installation loses prime on the tail of every draw. Break the first joint with a flexible connector so thermal movement and pump starts do not land on the bulkhead, carry the first valve on its own support off the pad, and keep machinery away from the fitting with a kerb or a bollard, because the outlet is the only fragile thing on the tank and a trailer tongue finds it. In a freezing climate trace or insulate the valve and the exposed run and let the body ice from the top down.

Chemical feed at a plant that buys by the tanker load

This is a feed and storage tank for operations that take delivery in bulk and dose out of it continuously: hypochlorite, coagulant or polymer at a municipal water or wastewater plant, an acid or caustic held for a process line at a manufacturing plant, a crop input solution at a co-op or blender, a wash, rinse or clean-in-place chemical at a food or beverage plant, glycol or a heat transfer fluid held for a plant loop, and a bulk replacement for the stack of totes that has been growing in the corner of the building. The pairing that matters is the volume and the shape: 2500 gallons is most of a tanker, and 107 inches puts that volume on a 90 inch circle so the pad stays small. Water held against fire is a different job with different rules, and the fire-water reservoir design guide is where that gets argued out properly rather than assumed. Before you settle on a silhouette, the complete buyers guide to the white 2500 gallon verticals walks through the shells at this capacity and what each one costs in floor and in height.

Class 500 from whichever of the two plants is closer

The SII-5090000C37 ships at class 500 as the sheet lists it, shipping at 90 inches by 90 inches by 107 inches, and it moves as an oversize load from Lincoln, Nebraska or Philippi, West Virginia. Give us the delivery ZIP and the plant choice is made for the shorter lane, which on a permitted move is the number that decides the invoice. The freight cost estimator prices it to your ZIP, and the listed price is before freight. Nine feet standing on a deck is a height and width problem as much as a weight one, so check the overhead lines, the tree line and the gate before delivery day, and confirm who is unloading. Slings under the body, never a hook through the manway, and the tank goes straight onto the finished pad and gets banded before the machine leaves the site. Fill with water to the manway, hold, read the base and the outlet, then drain and dry. Do the first delivery in daylight with somebody standing at the pad from the first gallon to the last. Leave room to walk all the way around it; the side of the tank nobody can see is the side that leaks.
