A 12000 gallon black vertical tank for bulk water and liquid storage
The Norwesco 12000 gallon vertical liquid storage tank in black, part number 43939, is a polyethylene tank 141 inches in diameter and 193 inches tall, weighing 2513 lb empty. It is a bulk storage tank for a pad: water for a farm, a ranch or a fire reserve, liquid fertilizer at a dealer, or process water at a plant. It comes with a 3 inch stainless steel bolted outlet fitting, a 3 inch reducer and a 3 inch by 5-1/2 inch siphon tube, plus a 22 inch manway on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals, with a service limit of 120 F. The resin is FDA compliant per Norwesco. Full of water it holds 100080 lb, about 50 tons, so the pad under it matters as much as the tank. Black keeps light out, which slows algae in stored water.
Is this the right size? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with what you are storing and where the pad is.
Where it goes
At 141 inches across and 193 inches tall, this tank needs a pad and a clear overhead; it is not a tank for a shed. The usual homes are a fertilizer plant or ag retailer, a ranch water system, a rural fire reserve and an industrial site that buffers water or a compatible liquid. Our 12000 gallon vertical tank buyer's guide walks through the decisions in order. For a fire reserve, the fire water reservoir design guide covers sizing and cold weather. For a reuse or rainwater system, see the water reuse tank layout guide. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 3 inch stainless steel bolted fitting low in the sidewall, with a 3 inch reducer and a 3 inch by 5-1/2 inch siphon tube. The siphon tube lets the tank draw down below the fitting height, so less liquid is stranded in the bottom. Your valve goes on the outlet before the first fill; support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
- Manway. A 22 inch manway on top for filling, a level sensor and access for cleaning. At 193 inches up, plan a fixed ladder or a platform if anyone will open it regularly.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet and manway positions for the piping layout.
Liquids heavier than 1.5 times water need Norwesco's heavy duty version of this size, not this tank. Check anything other than water against the maker's chemical guidance before it goes in, and ask us if you are not sure.
The pad and the first fill
A tank this size wants a level, continuous concrete pad larger than its 141 inch footprint, with no edge, drain or joint under the tank wall. Our note on concrete pad sizing for above ground polyethylene tanks gives the method; the pad design itself belongs to your engineer. Anchoring and wind load are site decisions the tank does not make for you. Fill with water the first time, slowly, and walk the fittings for weeps before anything else goes in.
Sizes nearby
One step down: the 10000 gallon vertical tank in white, without fittings. One step up, built for fertilizer: the 15000 gallon vertical fertilizer tank in yellow.
Shipping and receiving
The tank is oversize freight: 193 inches long on its side, 141 inches wide and tall, 2513 lb, on a flatbed from the nearest of Norwesco's plants in Fairfield, Texas, Hanford, California, St. Bonifacius, Minnesota and Washington Court House, Ohio. You need a clear approach for the truck and equipment to lift the tank off and stand it up; tell us what you have on site and we plan the delivery around it. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the site, check the part number against 43939 on the bill of lading and inspect the whole sidewall and the outlet fitting before the driver leaves.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Hanford, CA; St. Bonifacius, MN; Washington Court House, OH; Fairfield, TX. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 43939.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 12000 Gallon Black Vertical Liquid Storage Tank video (75 seconds) with dimensions, fittings and shipping notes.
