A 4200 gallon black vertical tank with a 3 inch outlet
The Norwesco 4200 gallon black vertical storage tank, part number 42020, is a rotomoulded polyethylene tank 102 inches in diameter and 131 inches tall, weighing 756 lb empty. It comes with a 3 inch polypropylene female NPT bulkhead fitting fitted with a 2 inch reducer as the outlet, so you can plumb it in either size, and a 16 inch threaded vented manway on top. Norwesco rates it for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 4200 gallons of water weighs 35028 lb. The resin is FDA compliant per Norwesco, Norwesco lists the tank as NSF 61, the service limit is 120 F, and Norwesco backs it with a 3 year warranty. Black keeps light out of stored water and slows algae.
Ready to order? Quote freight to your ZIP and add it to your cart above, or call 866-418-1777 with the site and the liquid.
Where 4200 gallons goes
This is a tank for a ranch water system, a rural fire reserve, a rainwater system on a large roof, an irrigation buffer, or a plant that takes liquid by the tanker load. At 102 inches across and 131 inches tall, the manway sits almost eleven feet up and the full tank weighs more than seventeen tons, so two things are settled before the order: a flat, level, continuous pad sized for that weight, and a fixed ladder or platform for whoever fills and inspects it. Our guide to the pad sizing framework and where its limits sit covers the slab. If the tank is a fire reserve, reservoir design for rural and remote sites covers sizing and freeze protection; if it collects roof water, the first flush diverter sizing guide explains what to put ahead of the inlet; for a reuse train that stores grey water or condensate by quality, see the reuse tank topology piece. Check the volume against your draw with the tank sizing calculator and the tank sizing guide.
Openings and fittings
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting with a 2 inch reducer, factory installed low in the sidewall. Leave the reducer in for 2 inch pipe and a 2 inch valve; take it out for a 3 inch valve where you want the faster drain or a pump that needs the bigger suction. On a tank this size the 3 inch run is usually the better choice. Support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
- Manway. A 16 inch threaded vented manway on top for the fill line, a float switch and cleaning. The vent has to pass the air that moves with the liquid; keep it clear, especially on a tank filled from a tanker.
- Liquid and temperature. At or below 1.5 specific gravity and at or below 120 F. Check anything other than water against polyethylene before the first fill.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height and the manway position for planning the plumbing and the ladder.
Sizes nearby
Norwesco builds a second 4200 gallon vertical tank, 41403; compare the two drawings if your spot has a height or footprint limit. One step down is the 4000 gallon black vertical tank, 40851; one step up is the 4995 gallon black vertical tank, 44822B.
Shipping and receiving
The tank ships LTL at freight class 400, upright, 102 by 102 by 131 inches and 756 lb, from Norwesco's Fairfield, Texas or Washington Court House, Ohio plant, whichever is nearer. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. A tank this size wants a forklift or a loader with straps at the stop; tell us what is there and we will plan the unload with you. At the tailgate, check the part number 42020 against the bill of lading, look over the full height of the wall and the bottom edge for transit damage, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Washington Court House, OH; Fairfield, TX. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 42020.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
