A 500 gallon heavy duty vertical tank in light blue for liquids heavier than water
The Norwesco 500 gallon heavy duty vertical liquid storage tank in light blue, part number 40150, is a flat bottom tank 48 inches in diameter and 73 inches tall, moulded in high density linear polyethylene and weighing 119 lb empty. Heavy duty means the wall is built for a 1.9 specific gravity rating: liquids up to 1.9 times the weight of water, which takes in every common liquid fertilizer, brines and most of the treatment chemicals a water plant or a farm handles, where a standard 1.5 tank runs out. It comes with a 2 inch polypropylene female NPT bulkhead fitting as the outlet and a 16 inch threaded vented manway on top. 500 gallons of water weighs 4170 lb and the heaviest liquid the rating allows brings a full tank to about 7923 lb. The service limit is 120 F, and Norwesco backs the tank with a 3 year limited warranty with full replacement, per its liquid storage catalog. Light blue is the middle option between white and black: darker than white against algae, lighter than black so the level still shows through the wall in good daylight.
Two ways to buy. Add it to your cart above with freight quoted to your ZIP, or request a written quote for a job that needs paperwork.
Which 500 gallon tank is yours
Norwesco makes this 48 inch body in more than one rating and colour, and the choice is the liquid, not the look. For water, rainwater and anything no heavier than 1.5 times water, the standard tanks do the job: the 500 gallon white standard tank or the 500 gallon black standard tank. For fertilizer, brine and heavy chemicals, you want 1.9: this tank in light blue, or the 500 gallon black heavy duty tank where the contents must be kept dark. Our 500 gallon vertical tank buyer's guide walks through the whole family, and our note on how polyethylene tank walls are sized for a specific gravity rating explains why the rating matters more than the gallon figure when the liquid is heavy.
Where it goes and what goes in it
The tank stands on a flat, level, continuous pad at least 48 inches across, with no slope, joint or drain under the floor; nearly four tons of liquid go through that floor when the tank is full of a 1.9 liquid. The 73 inch height puts the manway at the top of a short step, and the tank wants room to walk round. Check the liquid in our chemical compatibility guide before the first fill: polyethylene handles water, most fertilizers and many common chemicals, and the guide names the ones it does not. If the tank is part of a rural fire supply, our fire water reservoir design guide covers how a tank like this fits in. For the volume, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 2 inch ball valve threads straight into it. Support the valve and the first length of pipe on their own so the tank wall carries liquid, not plumbing, and with a heavy liquid use a valve rated for it.
- Manway. A 16 inch threaded vented manway on top: wide enough for a float valve, a level sensor and a brush. The vent lets air in as the pump draws down, so keep it clear.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the exact outlet height and the manway position.
Sizes nearby
A little bigger in the standard rating: the 525 gallon vertical liquid storage tank. A little smaller in black: the 310 gallon black vertical storage tank. Another 500 gallon vertical body: the 500 gallon HD vertical storage tank; tell us the liquid and we will confirm which of the two you want.
Shipping and receiving
The tank ships LTL from the nearest of Norwesco's plants in Fairfield, Texas; Hanford, California; Tooele, Utah; or Washougal, Washington, upright on a pallet; Norwesco lists the shipping size as 48 by 48 by 79 inches and the shipping weight as 164 lb. Two people walk it off a liftgate. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 40150 on the bill of lading, walk round the tank looking for scuffs that go through the wall, and fill it with water the first time before the heavy liquid goes in, so any problem shows up with something harmless in the tank.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Hanford, CA; Fairfield, TX; Tooele, UT; Washougal, WA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 40150.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 500 Gallon Blue Heavy Duty Vertical Liquid Storage Tank video (59 seconds) with dimensions, fittings and shipping notes.
