A 5025 gallon heavy duty black leg tank rated to 1.9 for the heaviest liquids you haul
The Norwesco 5025 gallon black heavy duty horizontal leg tank, part number 42602, is a polyethylene transport and storage tank 190 inches long, 92 inches wide and 96 inches tall, weighing 1709 lb empty. The heavy duty shell is rated for liquids up to 1.9 specific gravity, which is the difference between this tank and the standard 5025: it carries the dense fertilizers and chemicals a 1.5 tank cannot. The moulded legs let it sit on a trailer deck or a skid without a cradle. It comes with a 3 inch polypropylene female NPT bulkhead fitting with a 2 inch reducer as the outlet and a 16 inch threaded vented manway on top. Norwesco rates it to 120 F, states the resin is FDA compliant, lists its water tanks under NSF/ANSI 61 (the listing names no models), and backs it with a 3 year warranty. Full of water it holds about 41900 lb; at 1.9 specific gravity, close to 79600 lb.
Hauling something heavier than water? Call 866-418-1777 with the liquid and its specific gravity, or price freight to your ZIP and add it to your cart above.
Who needs 5025 gallons lying down
This is a bulk nurse tank or a stationary yard tank for a fertilizer dealer, a custom applicator, a large farm or a water hauler who needs the volume of a vertical tank but has to stay under a roof, a door or a bridge. At 190 inches it needs a deck close to sixteen feet, and at 96 inches tall it stands eight feet before the trailer height is added, so it is a dedicated trailer or a fixed pad, not a flatbed that does other work. Full of water it is nearly twenty-one tons, and with a 1.9 liquid nearly forty; buy the 1.9 rating only if you need it, because the standard shell is lighter if water and light fertilizer are all it will see. Strap through the leg recesses with the bands Norwesco makes for this tank, never over the manway. On the ground it needs a flat, continuous pad under all the legs, engineered for the full load. Our guide to Norwesco applicator and leg tanks for fertilizer and the DOT non-roadable trailer rules covers how these tanks are classified on the road, and the farm fleet DOT classification guide covers the agricultural exemption. For the volume, use the tank sizing calculator and tank sizing guide.
What goes in it
Water, the full range of liquid fertilizers including the dense ones, and the treatment chemicals polyethylene handles, up to 1.9 times the weight of water and 120 F. Check the liquid in our chemical compatibility guide before the first fill; the entries heavy duty tank buyers ask about most are urea solution, calcium chloride, phosphoric acid, potassium hydroxide and sulfuric acid. If you blend in it, read our note on fertilizer blend stratification and how to catch it before the spreader runs off spec; a tank this long layers badly if it is left to sit.
Openings and fittings
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the end wall, with a 2 inch reducer in it. Run 3 inch for fast transfer with a big pump, or leave the reducer in for 2 inch valves and camlocks. Support the valve and the first length of pipe so the fitting carries liquid, not a manifold.
- Manway. A 16 inch threaded vented manway on top: wide enough to fill from a pump, to drop a float in, and to get a hand and a brush inside. At eight feet up you will want a ladder or a platform at the manway.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet and manway positions and the leg layout for band and strap planning.
Sizes nearby
One size down is the 3725 gallon black leg tank; one size up is the 6025 gallon black heavy duty leg tank, the next shell with the same 1.9 rating. The same capacity in a standard duty blue shell is the 5025 gallon HDPE horizontal leg tank in blue.
Shipping and receiving
At 190 by 92 by 96 inches and 1709 lb, this tank ships at freight class 300 from the nearer of Norwesco's plants in St. Bonifacius, Minnesota and Washington Court House, Ohio, on a flatbed or a dedicated trailer. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. You need a large forklift or a loader with straps at the site; plan the route from the road to the pad before the truck is booked. Check 42602 against the bill of lading, look over every leg and the outlet boss for transit damage, and fill it with water the first time before it carries anything heavier.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: St. Bonifacius, MN; Washington Court House, OH. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 42602.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
