Snyder Industries 1900 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

A narrow alley and a tall strap line

Sixty-four inches across is why this tank exists. It fits between two tanks that are already standing, down the side of a building, into a chemical alley a wider shell cannot enter, and through doorways that stop the 90 and 96 inch tanks at the threshold; the cost of that footprint is 147 inches of height, and the height is where the site work goes. A shell this tall on a base this narrow has the highest center of gravity of anything in the family, so the strapping is designed with the pad rather than added after it: bands or cables to structure in the upper third, anchors set in the concrete, and a check after the first windy week and again after the first full summer, because an empty black tank in the sun loosens what was tight. The pad underneath still takes 15,846 pounds of water, or up to 30,107 pounds of contents at this sheet's rating, concentrated on a 64 inch circle, which is a heavier load per square foot than any wide tank here imposes; engineer that slab level and in full contact, per the concrete pad sizing guide, and put a berm sized to the tank around it wherever the liquid is regulated. Then plan the lid. At 147 inches nobody reaches the manway off a step; a fixed ladder and a platform with a rail are part of the installation, not an afterthought. A black wall hides the level, so the gauge is a sender read at the ground. The tank sizing calculator checks 1,900 gallons against the draw between deliveries, and the tank sizing guide covers the reserve and the freeboard.

The 1,900 gallon family, slim and wide

Four tanks in this table hold 1,900 gallons and only one of them does it on a 64 inch circle. The three 1780200 tanks stand 119 inches on a 72 inch base, each rated as its own sheet says and listed at 445 pounds except the N42 at 520; they are the choice when a 72 inch circle of floor is easier to find than the height. At the far end, SII-32118 lays 1,600 gallons down to 71 inches tall on an 86 inch circle for 264 pounds, and the 5050000C26 holds 2,000 gallons at 88 inches on a 90 inch base. Buy this tank when the floor plan, not the roof, is what you are fighting, and when the liquid is dense enough to need the 1.9 rating on this sheet; the same slim shell is also molded in a lighter grade, rated lower on its own sheet and lighter empty, which is the better buy for a liquid near water weight.

Still deciding between these? Freight to your ZIP often settles it; the wider tanks ship differently. Or call 866-418-1777 and we will walk the table with you.

The sheet lists the outlet as 16

• Outlet: the sheet lists the outlet as 16. That field carries no unit, material or thread on this sheet, so we print it as given and we do not read it as a pipe size; confirm the draw-off with us at order, naming the liquid and the pipe you are tying into, and the fitting, gasket and bolting are specified against that.
• Access: 18 inch threaded, vented manway at the top of 147 inches of shell, which means a fixed ladder, a platform with a rail, and a tie-off for whoever opens it.
• Service limit: 140 F / 60 C. Warranty: 3 year. The sheet lists two flange lines and no lug counts.

Whatever the draw-off turns out to be, 147 inches of liquid standing above it is the strongest suction head of any tank in this group, and that cuts both ways. In your favor, a transfer pump mounted below the fitting runs flooded deep into the tank and the last inches move quickly. Against you, the fitting and the first valve see more static pressure here than on a short tank, so the valve goes on its own support off the pad and the connection between fitting and hard pipe is flexible, never a rigid nipple carrying the weight of a pipe run. Fill down a dip tube to the floor rather than dropping the liquid the full height of the shell, keep the lid latched between deliveries, and give the wall above the working level a light at every opening. Where it freezes, protect the valve and the first pipe run; the shell itself takes ice from the top down.

Tight plant rooms that still need 1,900 gallons

The buyers are the ones out of floor space: a plating or finishing shop adding a dense acid or caustic tank between two that are already installed, a water plant squeezing a coagulant tank into a pump house corner, a chemical distributor putting bulk down the side of a warehouse, and a manufacturer whose only free footprint is an alley. Whether the chemistry wants a crosslinked wall or a high density one is the first question to settle, and the crosslinked versus high density polyethylene guide settles it on duty rather than price. Where containment is demanded, the Captor double wall freeboard guide shows what a double wall leaves usable at this volume, and a fire reserve is a separate discipline in a water-duty vessel, covered by the fire-water reservoir design guide.

Philippi, West Virginia, class 300

This tank is molded at Philippi, West Virginia and moves as freight at class 300 as the sheet lists it; 510 pounds in a 64 by 147 inch cube is a tall, narrow piece that loads lying down and has to be stood up at the site. Price the lane to your ZIP in the freight cost estimator, and the listed price is before freight. Stand it with straps under the body and a tag line, never a hook through the manway, and get the strapping to structure on before the lifting gear leaves the yard, because this is not a tank that should spend a week unrestrained. Fill with water to the manway, hold it a shift, walk the base and read the pad edge and the fitting, then drain and dry before the product comes. Put the ladder and the platform in the same purchase order as the tank; a tall tank whose lid is hard to reach is a tank nobody inspects. Write the outlet fitting size and material on the site plan; the replacement is ordered by those two words.
