Snyder Industries 300 Gallon ASTM XLPE Heavy Duty Vertical Storage Tank

The white half of the 8040000 pair

The same 8040000 shell is molded in black and in natural white, identical at 46 by 51 inches and 75 pounds, and the wall is the entire decision. Buy white when somebody has to know how much is in the tank by looking at it. A translucent wall shows the line from across the room, it shows you the sediment on the floor, and with a light held against the far side it shows you how clean the inside actually is. Buy black instead when light reaching the liquid is the problem. Inside the wider 300 gallon family this is also the short one: the 1011200 parts stand 82 inches on a 35 inch base, and this tank stops at 51 inches, so the lid clears a low joist, a mezzanine, a box truck door. The 1013000C26 holds 290 gallons on a 36 inch base at 72 inches, and the 1008200C26 goes the other way with 330 gallons on a 47 inch base at 50 inches, a shape very close to this one. What this shell does not give you is head: only 51 inches of column stands over the base, so let the discharge pump do the work. The pad takes everything, because a rotationally molded floor bears across its whole diameter, so pour it level and in full contact to the concrete pad sizing framework and set it inside containment sized to 110 percent of the tank where the liquid is regulated. Size the volume itself in the tank sizing calculator and take the working reserve and the thermal freeboard from the tank sizing guide.

One 300 gallon capacity in four different footprints

Read the table as two questions. First the wall: this natural white tank against the black 8040000N48 in the identical shell, and the answer is whether you would rather see the liquid or shade it. Second the shape: 46 by 51 inches here against 35 by 82 inches on the 1011200 parts, where the choice is floor space against ceiling height and nothing else, since all of them hold 300 gallons. The 1013000C26 is the tank for a room that is tight in both directions, and the 1008200C26 is the one to price if 330 gallons stretches the interval between deliveries far enough to matter.

Want the certified one or the plain one? Call 866-418-1777 and say what the inspector asks for; or request a quote on the row you need.

The lid is the vent, and the wall is the gauge

• Vent and fill: the sheet lists the outlet as 1 Manway / Lid and leaves the inlet blank, so one opening does the filling and the breathing. Match the delivery rate to what the lid can pass, or run a vent line genuinely sized to the pump, and never seal the lid while liquid is moving in or out.
• Level: the translucent wall is the primary gauge on this tank. Mark the wall in gallons once, during the water fill, and you have a reading that cannot drift, fail or lose power.
• Headspace: hold freeboard above 300 gallons. A liquid delivered cool and warming toward 140 F / 60 C takes up more room than it did on the truck, and sunlight on a white wall warms the top of the load first.
• Service limit: 140 F / 60 C.

A short wide tank breathes hard on a fast fill, because the air in the headspace has to leave through the lid at the same rate the liquid arrives. That is the number to think about here rather than suction head. Check the lid screen and the gasket every time the lid is off, keep the lid closed the rest of the time, and put a dip tube to the floor on the fill so the stream does not splash the upper wall or build static in the headspace. Below, give the base fitting a flexible connector to hard pipe and carry the first valve on its own support off the pad. Set the transfer pump low and close, fit a low level float so it never draws air, and keep the tank out of direct sun where you can, because light and warmth together grow algae in water service. Where the site freezes, trace or wrap the base valve and the first pipe run and leave the body to ice from the top down.

Operators who want to see the level

Make-down tanks, rinse water, process water, food plant duty, and any low room where the tank has to fit under something and still be read at a glance. This is also the shell that goes on a skid, because 75 pounds and a 46 inch base travel well. The cross-linked wall is the reason to pay for this part instead of a general purpose tank, and the comparison of cross-linked and high density polyethylene for chemistry duty gives the honest boundaries of that argument. Water sits well inside the 1.9 rating, but a fire reserve is a separate design with its own sizing and freeze rules, which the fire water reservoir design guide works through. The limitation is the one that comes with every translucent wall: it passes light, so anything that sunlight degrades belongs in the black shell instead.

Marked Tree to your yard at 75 pounds

Freight leaves Marked Tree, Arkansas at class 300 as the sheet lists it, the listed price is before freight, and the freight cost estimator prices the lane to your ZIP. At 75 pounds and 46 inches across, two people take it off the truck and set it on the pad with straps under the body, never a sling through the lid. Fill it with water to the lid once, hold it, and walk the pad edge and the base fitting looking for settlement or a weep, then drain and dry it. Do the gallon marks on the wall during that fill, with a bucket and a marker. It is twenty minutes of work that pays for itself the first time a gauge lies to somebody. Keep one spare gasket for the outlet fitting on the shelf; it is the part that fails on a holiday.
