The heavy-wall 300 gallon column tank
The Snyder 8030000N45 is a white high density linear polyethylene vertical liquid storage tank, 33 inches across and 94 inches tall, holding 300 gallons at 100 pounds. It carries the same 1.9 specific gravity wall as the big chemical tanks, rated for 4,754 pounds of contents against 2,502 for water, with 15 pounds more resin than the standard doorway 300, on the narrowest base Snyder puts 300 gallons on. A 10 inch lid on top, a 3 year warranty, and it ships as standard LTL freight.
Talk to a person first? 866-418-1777 reaches a tank specialist, not a call center; or see freight to your ZIP and add the 300 gallon tank to your cart above.
Nearly three times as tall as it is wide
A 33 inch base under 94 inches is a column of liquid, so the tank is strapped to a wall at two heights, and full it puts 4,754 pounds on that circle at the rating, which a slab or a paver pad in full contact carries. The reward is 300 gallons in a corner where nothing wider would fit, with nearly eight feet of head keeping a pump's suction flooded, and 100 pounds of resin is the wall for a dense liquid worked hard. The wall is sized under ASTM D1998; the HDPE tank wall thickness guide explains that logic and why a tall wall is inspected in the headspace. The 300 gallon vertical tank buyers guide compares the doorway shapes across makers; the tank sizing calculator sizes a day tank to the pump's rate and the refill schedule, and the tank sizing guide covers the reserve.
Snyder's 290 to 330 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 8030000N45 (this tank, heavy wall) | 300 | 33 x 94 in | 100 lb |
| 1011200N45 (ASTM certified) | 300 | 35 x 82 in | 85 lb |
| 1011200N42 (XLPE) | 300 | 35 x 82 in | 85 lb |
| 1011200C34 | 300 | 35 x 82 in | 85 lb |
| 1013000C26 | 290 | 36 x 72 in | 80 lb |
| 1008200C26 (squat) | 330 | 47 x 50 in | 85 lb |
The 1011200 tanks are the standard doorway 300s on a 35 inch base at 82 inches, the N45 certified, the N42 in cross-linked resin for oxidizers, the C34 in the general grade. The 1013000C26 holds 290 gallons on a 36 inch base at 72 inches, and the 1008200C26 lays 330 gallons down to 50 inches on a 47 inch base for the site with floor and no height.
Neighboring size a better fit? Every row links to its own page; freight to your ZIP is quoted on each, or call 866-418-1777.
Connections
- Access: 10 inch lid, 94 inches up, reached from a step; fill by hose or tote pump down a dip tube, and vent to the outside if the liquid fumes.
- Outlet: tell us the chemical when ordering and the bulkhead fitting is matched to it; run a flexible line to the pump suction and hang the valve off the floor, not the tank.
- Service limit: 120 F / 48 C.
A white 94 inch tank shows its level in daylight, and a sight tube on the outlet saves the step; a float switch for low level protects a pump. Put the dosing pump below the outlet, where it primes by gravity, keep the lid closed against vapor loss, and keep the tank out of direct sun where the chemical is light-sensitive. A 33 inch tank fits a standard spill pallet.
What it holds in practice
Treatment chemicals in a utility closet or a well house with a narrow corner, brine for a softener, acid and inhibitor feed at a cooling tower, and, with water in it, a well buffer or a cell of the small fire reserve the fire-water reservoir design guide describes. One chemical per tank, labeled.
Getting it to the pad
The 8030000N45 ships palletized as LTL freight (NMFC 156600-01) at a class rate; the freight cost estimator turns your ZIP into a freight number; the price on this page is before freight. Two people stand 100 pounds up and walk it through the door. Strap it at two heights, fill it to the lid once, hold it, and check the outlet fitting before it goes to work. Once it is full and holding, leave it alone for a day before the plumbing goes on; a settled tank is a quiet one.
Freight and documents
Ships from: Marked Tree, AR. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 8030000N45.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
