3,000 gallons, 1.5 specific gravity, siphon outlet
The Snyder 32267 holds 3,000 gallons of liquid in a white high density linear polyethylene shell 96 inches across and 109 inches tall, weighing 554 pounds. Its wall is rated for a specific gravity of 1.5, or 37,530 pounds of contents against 25,020 for water, which covers brine, fertilizer and dilute treatment chemicals as well as water. The outlet is a 2 inch polypropylene female NPT bulkhead fitting with a siphon tube that draws from the floor through a fitting mounted higher on the wall, so the tank sits flat in a containment basin or on a deck and still empties completely. A 20 inch threaded, vented manway on top.
Talk to a person first? 866-418-1777 reaches a tank specialist, not a call center; or see freight to your ZIP and add the 3000 gallon tank to your cart above.
Why a siphon outlet
A conventional bottom outlet needs clearance under the fitting for a valve and a pipe, which a spill pallet, a containment basin or a flat mezzanine deck does not give. A siphon outlet moves the fitting up the wall and reaches the floor with a tube inside the tank, so the tank stands on any flat surface and still drains to the last few inches. The trade is that a siphon needs a pump or a prime; it does not gravity-drain below the fitting height. The 3,000 gallon vertical tank buyers guide compares the class across makers, and the tank sizing calculator and the tank sizing guide settle the volume against the draw or the delivery interval.
The 96 inch 3,000 gallon tanks
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32267 (this tank, 1.5 SG, siphon outlet) | 3,000 | 96 x 109 in | 554 lb |
| 5130300N43 (1.5 SG, ASTM certified) | 3,000 | 96 x 111 in | 600 lb |
| 5130300N39 (1.35 SG, ASTM certified) | 3,000 | 96 x 111 in | 480 lb |
| 8390000C26 (low profile) | 2,650 | 102 x 97 in | 510 lb |
| 32288 (water tank) | 3,500 | 96 x 125 in | 550 lb |
The certified 5130300 tanks are the same base 2 inches taller with a conventional 3 inch bottom outlet and the paperwork; the N43 matches this tank's rating at 46 more pounds. The 8390000C26 is the low room answer at 97 inches on a 102 inch base, and the 32288 is a plain water tank at 3,500 gallons on this base.
Still deciding between these? Freight to your ZIP often settles it; the wider tanks ship differently. Or call 866-418-1777 and we will walk the table with you.
Outlet and manway
- Outlet: 2 inch polypropylene female NPT bulkhead fitting with an internal siphon tube to the floor; a PVC or CPVC adapter, a flexible transition, and a valve supported off the deck.
- Access: 20 inch threaded, vented manway, a step-ladder reach.
- Service limit: 120 F / 48 C.
Full, the tank loads a 96 inch circle to 37,530 pounds at the rating, a slab or a deck checked for that load in full contact under the whole floor. Strap it while empty, fill through a dip tube so dense liquid does not splash the lid, keep the vent clear, and prove the siphon draws to the floor on the water test. A white tank shows its level in daylight; in a pump room plan a sender at the outlet.
Who buys this tank
Liquid fertilizer and brine at a co-op, dilute treatment chemicals at a plant, a basin-mounted reagent tank with no clearance underneath, and bulk water where a heavier wall is wanted outdoors. In a freezing climate a solution expands against a wall not designed for ice; house the tank or keep it above freezing.
Delivery day
At 96 inches across and 109 inches long on the deck the 32267 is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. A forklift with long forks sets 554 pounds on the pad. Water-fill with a hold, drain through the siphon to prove it, and check the fitting before the product goes in. Keep the delivery paperwork with the tank; the serial number on the shell is what a warranty claim starts from.
Freight and documents
Ships from: Albertville, AL. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32267.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
