4,100 gallons on a 102 inch floor, in green
The Snyder 32329 is a 4,100 gallon vertical water tank in green high density linear polyethylene, 102 inches across and 130 inches tall, 714 pounds empty. It is the step between the 3,500 gallon tanks on the 96 inch floor and the 5,000 gallon shapes, and it carries a heavy wall for its size. Green is the color for drinking water in view. A 26 inch threaded vented manway on top, a 1-1/2 inch polypropylene inlet and a 2 inch polypropylene outlet. Rated for a specific gravity of 1.0.
Buying for a site, a fleet or a district? Request a written quote with freight to your ZIP, or add it to your cart above and call 866-418-1777 with any question on the fit.
Seven hundred pounds of wall
At 714 pounds this tank carries 179 more pounds of resin than the 3,500 gallon 32294 for 600 more gallons, and the resin is in the wall. On a water tank that does not raise the rating, which stays at 1.0; it raises the number of years the tank stands full in the sun before the wall shows it. Buy it for the wall as much as for the gallons.
Between 3,500 and 5,000 gallons
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32294 | 3,500 | 96 x 125 in | 535 lb |
| 32327, black | 4,100 | 102 x 130 in | 714 lb |
| 32329 (this tank) | 4,100 | 102 x 130 in | 714 lb |
| 32368 | 5,000 | 119 x 116 in | 805 lb |
The 5,000 gallon 32368 is the interesting comparison: 17 inches wider and 14 inches shorter, with 91 more pounds of wall for 900 more gallons. If the pad can take 119 inches, the 5,000 is more water per pound of resin; if the pad is 102 inches, this tank is the most water that fits. The black 32327 is this exact tank in the working-site color.
Need a different size? Every tank in the table is in stock programs; ask for a quote on the one that fits, or call 866-418-1777.
Thirty-four thousand pounds
Full, the tank weighs 34,194 pounds on a 102 inch circle, carried high. A reinforced, level slab in full contact with the whole floor is the requirement; the concrete pad sizing guide works the ACI 360R-10 method for this load. Service limit is 120 F / 48 C. The manway is a ladder job at 130 inches, so run the fill to the top inlet and keep the manway for inspection with its vent clear; the vent moves the air displaced by 4,100 gallons.
Ports
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting on top.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting at the base; full-port valve, union, pump.
- Access: 26 inch threaded, vented manway, large enough to climb in for a cleanout.
A sight tube on the outlet is the simplest gauge; the level gauge selection guide compares sensors that read through a green poly wall.
What 4,100 gallons does
A private fire reserve with a margin over the usual rural minimum, per the fire-water reservoir design guide; a community or ranch drinking water store; the raw water block of a reuse train in the industrial water reuse topology guide. Confirm the capacity against your draw with the tank sizing calculator and the tank sizing guide.
Oversize freight and the first fill
At 102 inches across it ships as oversize freight (NMFC 156600) on a flatbed, quoted by lane through the freight cost estimator; the listed price is before freight. Plan a loader with straps for 714 pounds and 130 inches of length. Fill in stages the first time, watching the slab and the outlet fitting as the head comes on, per the hydrostatic test methodology guide.
Freight and documents
Ships from: Merced, CA; Albertville, AL. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32329.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
