Snyder Industries 4400 Gallon ASTM Black Heavy Duty Vertical Storage Tank

Tiedown lugs before the wind gets a chance

A tank better than fifteen feet tall on a circle seven and a half feet across has the highest centre of gravity in this size class, so on this one the anchoring is designed before the pad is poured rather than added after it. The sheet lists four tiedown lugs, which is the manufacturer telling you where the load goes: cables or bands from those lugs to structure or to anchors set in the slab, tight before the first fill, checked after the first windy week and again after the first full summer, because black polyethylene grows in the sun and the strap that was tight in spring is slack in August. The window nobody plans for is the one between delivery and first fill, when an empty tank at 1,450 pounds with fifteen feet of wall is a sail. The reward for all of that is the footprint: a 90 inch circle goes behind a building, between two vessels that are already there, or down a chemical alley a wide tank would block. Full at the rating there are 69,722 pounds on that circle, which is a heavier load per square foot than any wide tank in this size carries, so the slab is engineered to the framework in the concrete pad sizing guide, level and in full contact, sized for the rated case rather than the 36,696 pound water case, inside a berm sized to the tank where the liquid is regulated. Measure the clearance above the manway as well: 182 inches plus a platform, a fill line and a vent is the real height this tank asks for. Then run 4,400 gallons against the draw between deliveries in the tank sizing calculator, with the reserve and the thermal freeboard from the tank sizing guide.

The slim 4,400 shell and the wide tanks near it

Inside this shell the split is weight and grade. This tank and the N42 are both listed at 1,450 pounds where the N40 and N46 are listed at 1,100, which is the sheet's own record of how much more wall the heavier tanks carry, and we print what it says. Take this one when the liquid is heavier than water and the floor is the thing you do not have: the 1.9 rating is what it is for, and nothing else on this list is rated as heavy. The N42, N40 and N46 are the cross-linked grades in the same 90 by 182 inch shell, each rated as its own sheet says, with the N46 black for a load that light spoils. If the constraint flips and the roof becomes the problem, the 7421100C34 puts 4,300 gallons on a 120 inch base at 104 inches and the 7000400N29 lays 4,500 gallons down to 91 inches on a 143 inch base, both far easier to receive and both wanting a great deal more floor.

Need two of them? Request a written quote for the pair with freight to your ZIP, or call 866-418-1777 and we will price the truck once.

The sheet lists the outlet as 14

• Outlet: the sheet lists the outlet as 14. That is the field as published and it is not a pipe size, so we do not print it as one. Give us the liquid and the pipe you are tying into at order and the base fitting, gasket and bolting are specified then.
• Access: 18 inch threaded, vented manway on the top head, 182 inches up, which means fixed access and a rail rather than a leaned ladder; fill through a dip tube to the floor so a delivery does not free-fall fifteen feet and aerate the load, and run the vent outdoors on anything that fumes, sized to the delivery pump.
• Service limit: 120 F / 48 C.

Better than fifteen feet of liquid standing above the base is the most suction head in this size, and it cuts both ways. A transfer pump set below the outlet runs flooded to the last few inches and empties the tank in a shift, which is the upside. The downside is that the same head sits on the fitting, the first valve and the first joint all day, every day, and with a dense liquid at 69,722 pounds it sits harder than water would. So the connector to hard pipe is flexible, the first valve rides on its own support off the pad, nothing rigid bolts to the wall, and one spare gasket for whatever fitting is specified lives on the shelf. A low level float stops the pump before it pulls air. Keep the manway closed between deliveries, name the one liquid on the wall in letters readable from the gate, and put a light on the band of wall above the liquid line at every opening, because on a tank this tall that band is the part nobody sees from the ground. Where the site freezes, trace or wrap the valve and the first pipe run; the body ices from the top down without harm.

Heavy liquid where there is no floor to spare

This tank lands on crowded sites: a treatment plant squeezing a dense coagulant tank between two that are already installed, a plating or metal finishing shop with a narrow chemical alley and a tall bay, a mineral or food processor on a concentrated process liquid, a co-op putting a heavy blend behind the warehouse rather than in front of it. The 1.9 rating and the 90 inch circle are the two reasons it is there, and neither of them is about volume. Where site rules require a second wall around a dense liquid, the Captor double wall freeboard guide works out what containment costs in usable gallons, which is the figure people forget when they draw a berm around a slim tank. Water is well inside this wall and a fire reserve is a system rather than a vessel, which the fire-water reservoir design guide sets out. Where storage sits between the treatment stages of a reuse train, the industrial water reuse tank topology article shows where a slim vessel of this size fits.

Lincoln to the pad, fifteen feet on the deck

The 5210000N51 is molded at Lincoln, Nebraska and moves as freight at class 300 as the sheet lists it, shipping at 90 inches by 90 inches by 182 inches. At better than fifteen feet long on the deck it rides as a permitted load, and the route matters as much as the rate: walk the gate, the turn into the pad and the overhead lines before delivery day, because a load this long does not reverse out of a bad approach. The freight cost estimator prices the lane to your ZIP, and the listed price is before freight. A crane stands 1,450 pounds up on the lifting lugs the sheet lists, with straps under the body and never a hook through the manway, and it lands on the anchors that were set with the pad, with the tiedowns tight before the crane releases. Water test before product: fill to the manway, hold it, read the base, the pad edge and the fitting from the ground with a second person watching the fill, then drain and dry. Check the band tension a week after the first fill, because a tank settles and a tight strap goes slack. Photograph the outlet fitting from below before the pipe goes on; a slow weep is easier to compare against than to describe.
