6,900 gallons, heavy duty, rated to 1.9 specific gravity
This Snyder heavy duty vertical tank holds 6,900 gallons of liquid in a white high density linear polyethylene shell 120 inches in diameter and 153 inches tall, weighing 1,450 pounds empty. Its wall is rated for a specific gravity of 1.9, which puts the maximum contents at 109,337 pounds against 57,546 for the same volume of water: the full tanker load of a treatment plant's caustic, ferric or alum in one vessel, on a ten foot pad. A 3 inch polypropylene female NPT bulkhead fitting at the outlet and an 18 inch threaded, vented manway on top.
Ready to price it? The listed price is before freight; quote freight to your ZIP in a few seconds, then add to cart above or call 866-418-1777.
The bulk chemical tank at plant scale
Six thousand nine hundred gallons is the size at which a plant takes a full tanker and stops paying for partial loads, and the 1.9 wall is what lets that tanker carry concentrated product rather than dilute. The pad is the project: an engineered slab in full contact under the 120 inch floor, sized for 109,337 pounds and level enough that 153 inches of tank stands plumb. The tank sizing calculator sizes the volume to feed rate and delivery interval, and the tank sizing guide covers the reserve. The day tanks that usually stand beside a bulk tank like this are covered in the 2,000 gallon, 500 gallon and 300 gallon vertical tank buyers guides.
The 120 inch family, 6,500 to 7,000 gallons
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 6,900 gallon heavy duty (this tank, 1.9 SG) | 6,900 | 120 x 153 in | 1,450 lb |
| 7140000C34 | 6,900 | 120 x 153 in | 1,300 lb |
| 7140000N49 (black, 1.5 SG) | 6,500 | 120 x 153 in | 1,450 lb |
| 5300400N40 | 6,600 | 120 x 158 in | 1,900 lb |
| 5300700N40 (low profile) | 7,000 | 142 x 122 in | 1,400 lb |
The 7140000C34 is the same mold with 150 pounds less resin, for the liquid that does not need the full 1.9 wall. The black 7140000N49 is the light-blocking version at a 1.5 rating. The 5300400N40 carries 450 more pounds of wall on the same base, 5 inches taller, and the 5300700N40 is the low room answer: 7,000 gallons at 122 inches on a 142 inch base.
Want us to check the fit? Send the site dimensions to 866-418-1777 or through a written quote request and we will confirm the tank, the pad and the freight.
Ports and access
- Outlet: 3 inch polypropylene female NPT bulkhead fitting at the bottom of the sidewall; a PVC or CPVC adapter, a flexible transition, an expansion joint and a valve supported off the slab.
- Access: 18 inch threaded, vented manway, vented outside on caustic and acid service; fill through a dip tube to the floor.
- Service limit: 120 F / 48 C.
Thirteen feet of head over a 3 inch outlet is real pressure at the bulkhead, so the nut is checked after the first full fill and the pipe is never allowed to hang from the fitting. Level is a hydrostatic sender at the outlet or radar on the manway, never a climb.
Typical duty
Caustic, coagulant and acid bulk storage at water and wastewater plants; reagent storage at chemical and food plants; and, with water in it, a fire reserve sized under NFPA 22 as the fire-water reservoir design guide describes, with the thickest wall Snyder puts on this mold.
Freight to your ZIP
At 120 inches across and 153 inches long on the deck this is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. A crane or a large telehandler lifts 1,450 pounds onto the slab. Water-test in stages with a hold, then drain and dry before the first tanker.
Freight and documents
Ships from: Lincoln, NE; Philippi, WV. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 7140000C37.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
