7,000 gallons at 1.5 specific gravity under a barn roof, ASTM certified
The Snyder 5300700N43 is a white polyethylene vertical liquid storage tank, 142 inches across and 122 inches tall, holding 7,000 gallons at 1,400 pounds. Its wall is rated for a specific gravity of 1.5, or 87,570 pounds of contents against 58,380 for water, so it holds brine, fertilizer solution and coagulant as delivered as well as water, it is sold with ASTM certification for jobs that need the paper, and the twelve foot base puts a tanker load and a working reserve under a ten foot roof with the manway reached from a short platform. It carries an 18 inch threaded, vented manway and a 3 year warranty, and it travels as oversize freight.
Is this the right 7000 gallon tank? Call 866-418-1777 with the liquid, the site and the ceiling height, or get freight to your ZIP and add it to your cart above.
Seven thousand gallons in the widest shell, in the middle wall
A water-rated wall is for water and nothing heavier; the heaviest wall is for concentrated acid; a 1.5 wall is the middle, sized for brine, fertilizer solution and coagulant as delivered and every water application, with margin. ASTM D1998 is the standard the certification is written to, and a tank meets it in the wall; the HDPE tank wall thickness guide explains the sizing logic and why the headspace is where a wall ages, and the freeboard sizing guide works out the usable volume once thermal expansion is accounted for. The shape is the low one: 87,570 pounds on a 142 inch circle sits close to the ground and needs the least strapping in the line, but the widest floor spans any hollow in a gravel base and cracks there when full, so the pad is an engineered slab in full contact under the whole circle, per the concrete pad sizing guide. The tank sizing calculator tells you whether 7,000 gallons covers the draw, and the tank sizing guide covers days of supply.
Grades on the 142 x 122 inch tank, and the sizes beside it
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 5300700N43 (this tank, 1.5 SG, ASTM certified) | 7,000 | 142 x 122 in | 1,400 lb |
| 5300700N45 (1.9 SG, ASTM certified) | 7,000 | 142 x 122 in | 1,900 lb |
| 5300700N40 (XLPE) | 7,000 | 142 x 122 in | 1,400 lb |
| 5300700N42 (XLPE, heavy wall) | 7,000 | 142 x 122 in | 1,900 lb |
| 5300700N46 | 7,000 | 142 x 122 in | 1,400 lb |
| 7140000C26 (ten foot base) | 6,900 | 120 x 153 in | 1,300 lb |
| 7440000N40 (tall, XLPE) | 7,500 | 102 x 234 in | 2,450 lb |
The N45 is the certified 1.9 wall, 500 pounds heavier, for ferric at strength and the heavy brines; the N40 and N42 are cross-linked polyethylene for oxidizers, the N42 the heavy wall, and the N46 another linear grade at this weight. The 7140000C26 holds 6,900 gallons on a 120 inch base at 153 inches for a site with less floor and more height, and the 7440000N40 stands 7,500 gallons of cross-linked resin on a 102 inch base at 234 inches.
Comparing across brands too? Call 866-418-1777; we carry Norwesco, Snyder, Chem-Tainer, Enduraplas and Bushman and will say which one fits, or price the freight first.
Bulkheads and lid
- Access: 18 inch threaded, vented manway, 122 inches up; filled by truck through a dip tube, vented outside on anything that fumes, and size the vent for a tanker's unload rate.
- Outlet: tell us the liquid when ordering and the bulkhead fitting is matched to it; a flexible connector between the bulkhead and hard pipe, an expansion joint, and the valve supported off the slab.
- Service limit: 120 F / 48 C.
- Listing: ASTM certification.
The white wall shows the level in daylight; fit a sender read at ground level so nobody climbs for a number, and a low-level switch protects the pump. Mount the pump below the outlet so it primes by gravity, keep the manway closed against vapor loss, and keep the tank out of direct sun where the liquid is light-sensitive. Where it freezes, insulate or drain the outlet valve and the first length of pipe; the body takes ice from the top down without harm.
The tanker unload
A tanker's pump moves liquid faster than a manway vent can pass air, so either the vent is sized to the unload rate or the fill comes in through its own top bulkhead with a separate vent line. A fill pipe to the floor keeps the liquid from free-falling and foaming. Nobody walks away during the first fill: the slab edge and the outlet fitting are checked as the level climbs, and the log takes the date and strength of every load that follows.
Day-to-day duty
Coagulant, brine and fertilizer solution delivered by tanker with a reserve into a barn or a shed, at plants and farms that need the certification on file, well storage for a community system under a low roof, and a fire reserve of the kind the fire-water reservoir design guide describes, where the low center of gravity counts. One liquid per tank, labeled.
From the plant to your site
At 142 inches across the 5300700N43 is oversize freight (NMFC 156600) on a flatbed at a lane rate, wider than most loads on the road, so the estimator's lane matters; the freight cost estimator quotes the haul to your ZIP; what is listed is the price before freight. A crane or a forklift with long forks sets 1,400 pounds on the slab, and the slab is checked flat before the tank lands. Fill it to the manway once, hold it, check the outlet fitting, and keep the certification paperwork with the project file. Write the fill date on the manway with a paint marker; it answers the first question anyone asks about a tank.
Freight and documents
Ships from: Lincoln, NE. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5300700N43.
