Snyder Industries 850 Gallon HDPE Vertical Liquid Storage Tank - Sulfuric Acid Resin #880046

The certified acid tank for a small plant

Concentrated sulfuric acid weighs nearly twice what water does and attacks the wall of an ordinary linear polyethylene tank from the inside, at the surface and in the vapor space above the liquid; Snyder's N30 resin is compounded for that service, so the tank is sized for the acid's weight and its chemistry together, and the certification against ASTM D1998 is what says the wall was sized that way. The HDPE tank wall thickness guide explains the sizing logic and why the headspace, not the wetted wall, is where an acid tank is inspected. Full, it puts 13,469 pounds on a 48 inch circle at the rating, which a slab in full contact carries; a single wall tank of acid stands inside a berm or a containment tub sized to it, with the eyewash and the shower within reach, strapped to the wall because a 48 inch base under nearly ten feet of dense liquid has a high center of gravity. The 850 gallon vertical tank buyers guide compares every maker's version of this volume; the tank sizing calculator sizes the tank to feed rate and delivery interval, and the tank sizing guide covers the reserve; acid expands more than water with temperature, so the reserve includes freeboard.

The two sulfuric 850s, and the sizes beside them

The 1810200N30 is the same 850 gallons of sulfuric resin at the same weight, a few inches shorter, without the certification on file. The 1831000C26 holds 1,000 gallons in the general grade on a 60 inch base at 89 inches, and the 32441 is the light water tank on this base.

Height or floor the limit? The table has both shapes; freight to your ZIP is quoted on each row, or call 866-418-1777 with the site.

Connections

• Access: 18 inch threaded, vented manway, 117.7 inches up; fill through a dip tube, vent to a scrubber or outdoors, never into a room, and size the vent for the delivery pump.
• Outlet: specify an acid-rated bulkhead fitting and gasket when ordering; a flanged transition and a valve supported off the floor.
• Service limit: 120 F / 48 C.
• Listing: ASTM certification.

Choose a level sender rated for concentrated acid and read it at ground level. Acid draws water from the air and heats when it does, so the manway stays closed and the vent carries a drying trap. Never add water to the tank; dilution is done elsewhere, water first.

Receiving a delivery

A delivery truck's pump can push air out faster than a stock vent can pass it, so the vent is sized for the unload rate or the fill goes through a dedicated top bulkhead with its own vent line. The fill pipe runs to the floor so the acid does not free-fall and fume. The first delivery into a new tank is watched from start to finish, with the floor and the outlet fitting checked as the level climbs, and the log takes the date and strength of every load that follows.

What it holds in practice

Sulfuric acid for pH control at a small water or wastewater plant that keeps certifications on file, regeneration acid at a demineralizer, pickling and plating acid at shop scale, and any indoor vessel of concentrated acid that has to come through a door; with water in it, a fire reserve of the kind the fire-water reservoir design guide describes, though a tank bought in this resin is bought for acid. Acid only, labeled for both inspectors at once.

Getting it to the pad

At 117.7 inches long on the deck the 1810000N30 ships as oversize freight (NMFC 156600-02) at a lane rate rather than a class rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. Two people stand 220 pounds and walk it through a door on a dolly. Water-fill it once to the manway, hold it, then drain and dry completely before the first acid delivery, and keep the certification paperwork with the project file. Once it is full and holding, leave it alone for a day before the plumbing goes on; a settled tank is a quiet one.
