A 160 gallon white vertical tank with a 2 inch outlet on a 28 inch footprint
The Norwesco 160 gallon vertical liquid storage tank, part number 44536, is a white polyethylene tank 28 inches in diameter and 69 inches tall, weighing 55 lb empty. It stands on its own flat base and comes with a 2 inch polypropylene female NPT bulkhead fitting as the outlet and an 8 inch threaded vented lid on top. The 2 inch outlet is the reason to pick this tank over the smaller sizes with a 1-1/4 inch port: it drains faster and feeds a pump without starving it. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 160 gallons of water weighs about 1330 lb. The service limit is 120 F, and Norwesco backs it with a 3 year limited warranty.
Standard or heavy duty? Call 866-418-1777 with the liquid and we will say which rating it needs, or get freight to your ZIP and add this one to your cart above.
Where it goes
Twenty-eight inches across is a footprint that fits between two machine bases, on half a pallet position, beside a boiler, in the bay of a service body or against a plant room wall, and 69 inches of height is what makes that footprint hold 160 gallons. It goes through a standard doorway upright. Check the height first: 69 inches plus room above it to get the lid off and a hose in, measured to the lowest duct, light or header over the spot. The lid is at head height for most people, so plan a fill line or a pump rather than buckets. A tall tank wants a level floor; a slab that falls toward a drain leans a 69 inch column enough to see. Full of water it puts about 1330 lb on a 28 inch circle, and a rotationally moulded base bears on everything it touches and nothing else, so it needs a flat, continuous surface under the whole base.
What goes in it
Water, liquid fertilizer, wash water and the treatment chemicals that polyethylene handles are the normal loads. Liquids heavier than 1.5 times water belong in the heavy duty version: the 160 gallon heavy duty vertical tank is the same capacity rated 1.9. Keep the contents under 120 F. White shows the level against light behind the tank; black keeps light out and slows algae in stored water. Our buyer's guide to the 160 gallon 28 by 69 inch vertical tank is written around this exact tank, and the tank sizing calculator and tank sizing guide settle whether 160 gallons is the right number.
Openings and fittings
- Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 2 inch ball valve, camlock or hose adapter threads straight in. Dry-fit the valve so the handle clears the wall, seal the threads, and support the valve and the first length of pipe on their own; a 2 inch valve with a hose on it is more weight than a tank wall should carry.
- Lid. An 8 inch threaded vented lid. Wide enough for a hose, a float switch or a small pump inlet; the vent lets air in as the tank drains so the walls are never pulled inward.
- Drawing. Norwesco's drawing for this tank is linked on this page under Technical Drawing. It gives the outlet height and the lid position for planning the pipe run.
Sizes nearby
Same tank in black: the 160 gallon black vertical storage tank. Same tank rated 1.9 for heavier liquids: the 160 gallon heavy duty vertical tank. One size down and one size up in black: the 150 gallon black vertical storage tank and the 165 gallon black vertical storage tank. The colour and rating swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL from the nearer of Norwesco's Lancaster, Ohio and Sheldon, Iowa plants, 28 by 28 by 69 inches on a pallet at a ship weight of 55 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number 44536 on the bill of lading, look at the base and the 2 inch fitting before the driver leaves, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Sheldon, IA; Lancaster, OH. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44536.
See this tank
Product video. Watch the 160 Gallon Vertical Liquid Storage Tank video (61 seconds) with dimensions, fittings and shipping notes.
