Snyder Industries 1000 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

Two plants, California and Nebraska, on one cross-linked part

Two origins on one part number is worth more than it sounds. Chowchilla, California serves the Pacific states, the Southwest and the Mountain West on short lanes; Lincoln, Nebraska serves the Plains, the Midwest and most of the eastern half of the country on lanes that are shorter still from the middle out. Between them, very little of the map is a long haul, and on a tank the sheet gives at 320 pounds against class 300 the lane is where the money moves, because three hundred and twenty pounds is not a weight a carrier prices. What it does price is the deck, and this is a wide parcel: 74 inches across is over six feet of trailer width, so it rides as a single piece rather than nesting with anything, and it is the one number to check before the requisition goes in. Run the ZIP through the freight cost estimator and read the listed price as before freight. What the width costs on the trailer it returns on the site. At 69 inches the shell fits under a roof a tall 1,000 gallon tank cannot clear, and the manway is reached from a modest platform rather than a tall one. The ground carries the trade. The 1.9 rating allows 15,846 pounds of contents and plain water alone puts 8,340 pounds inside, and because a rotationally molded floor bears on its whole floor, that load spreads across a 74 inch circle, which is gentler per square foot than any narrow tank at this volume. Even so, the slab is engineered to the concrete pad sizing guide, level and in full contact, inside a berm sized to the tank where the liquid is regulated, because a wide tank on a pad with one low corner puts its weight on that corner. Band it anyway while it is empty; wide and low is the least wind-sensitive shape in the range and the one people leave unbanded, and a black wall grows and shrinks a little every day in the sun. Size the volume against the draw in the tank sizing calculator and take the reserve and thermal freeboard from the tank sizing guide.

The wide 1,000 among the tall ones

At 1,000 gallons the real choice is a shape, not a wall. The three 1831000 tanks put the same volume on a 60 inch base and stand close to seven and a half feet, which is the buy when floor is scarce; each is rated as its own sheet says. This tank goes the other way, trading a wider circle for a shell that clears a low roof, and it is the one to pick when the building is the constraint and the slab is not. Its own stablemate is the high-density wall molded in this identical shell, listed separately and rated as its own sheet says: choose between them on chemistry rather than on fit, because they are the same tank in every dimension. The 1810000C34 is the slim, very tall step down in volume for an alley, and the 1710000C26 is the widest and lowest step up.

Comparing against another maker? Send the competing spec to 866-418-1777 or a quote request and we will show the differences honestly.

Molded ladder lugs to a manway at five feet nine inches

• The opening and the climb come first: an 18 inch threaded, vented manway at the top of a 69 inch shell, five feet nine inches up, and the sheet lists molded ladder lugs on this tank, which is what a ladder is anchored to. Five feet nine is a short climb rather than a tall one, and the lugs mean the ladder belongs to the tank instead of leaning on it; still put a proper platform and rail where anyone opens the cover regularly.
• Outlet: the sheet gives the outlet as "1 Manway / Lid" and no bottom fitting size appears anywhere on it. We print the field as it stands rather than invent a bulkhead diameter. Tell us the liquid and the draw-off you need at order and we confirm what this molding takes, in what material, with what gasket, before anything is drilled.
• Fill and vent: a permanent fill connection landed at the manway, a dip tube to the floor so the incoming stream does not free-fall and foam, the vent piped outdoors on anything that fumes, and the vent sized to the delivery pump.
• Service limit: 120 F / 48 C. Warranty: 3 year. Rating: specific gravity 1.9 as the sheet gives it, the highest allowance of any tank in this group.

The rating is the reason this shell exists, so respect what it implies. A dense liquid at the top of the allowance puts 15,846 pounds inside a tank that weighs 320 pounds empty, which means the pad, the bands and the base plumbing all see forces a water tank never shows them: the draw-off rides on its own support off the pad with a flexible connector to hard pipe, and nothing rigid is bolted to the shell. The cross-linked wall is the other half of the specification and it is a chemistry decision rather than a strength one. Because the wall is black, the level and the sediment are both invisible, so a sender and a local gauge are part of the install, and inspection is a light on the band above the liquid line every time the cover is off, with the thread and the gasket seat checked while the light is out and the date written down. Freeze protection goes on the base piping and the first valve, never on the body.

Warm chemistry on a low pad

A dense process liquid at a plant with a low chemical building, a plating or finishing line feed, a brine or concentrate at a food or municipal plant, a mixing and dosing skid that needs real volume under a roof, and any outdoor pad where the liquid has to stay dark through a full summer. The high allowance is what gets it specified for the heavy liquids; the low shell is what gets it into the building. Whether the cross-linked wall is genuinely the right buy or whether a high-density wall would do the same work is the question worth settling before the order rather than after, and our guide to when cross-linking matters for chemistry duty answers it chemical by chemical instead of in generalities. Where a site rule or an insurer wants the liquid inside a second wall, the Captor double wall freeboard guide works out how much usable volume a contained vessel really returns at this size. Water sits far inside the rating, but a private fire reserve is a separate specification in a water-rated vessel, as the fire-water reservoir design guide explains.

Two origins, 320 pounds, and a wide deck footprint

Class 300 and 320 pounds is what the sheet gives, from Chowchilla, California or Lincoln, Nebraska, and the right answer is whichever of the two is closer to your dock; tell us the destination and price the lane to your ZIP in the freight cost estimator, reading the listed price as before freight. At 74 inches across this is a wide piece on the deck and a forklift with long forks or a small crane sets it down, straps under the body and never a sling through the manway or the ladder lugs. It goes onto the cured pad inside its containment rather than onto a staging slab, and it gets banded before the machine leaves. Fill it with water to the manway, hold it, walk the whole pad edge twice looking for movement or a weep, then drain and dry it before the working liquid arrives. On a tank rated this high, keep the sheet's rating written on the wall beside the liquid's name, because the next person to fill it will not read this page. Save the pallet; a tank that ever has to move again is easier to move on it.
