1,300 gallons in opaque white at 1.9 specific gravity
The Snyder 1830400N52 is an opaque white high density linear polyethylene vertical liquid storage tank, 72 inches across and 87 inches tall, holding 1,300 gallons at 320 pounds. Its wall is rated for a specific gravity of 1.9, or 20,600 pounds of contents against 10,842 for water, the chemical-grade wall for ferric chloride at strength, concentrated acids and the heavy brines, and the opaque resin keeps light off the contents the way a black tank does while staying white enough to show a shadow line of the level in daylight. The six foot base stands under a standard eave with the 18 inch threaded, vented manway reached from a step. It ships as standard LTL freight.
Know your ZIP and your ceiling height? Freight to your ZIP takes seconds, and 866-418-1777 will confirm the height; then add it to your cart above.
Five totes of chemical, out of the light
Light drives the breakdown of hypochlorite, of some coagulants and of most of the organic chemicals a plant stores; a standard white wall lets some of it through, a black wall lets none through and hides the level, and the opaque white is the compromise Snyder molds for chemical service, dark inside and readable outside. On top of that the 1.9 wall is sized for a liquid nearly twice as dense as water, so the dense coagulants and acids are covered as well as the light-sensitive ones. Full, it puts 20,600 pounds on a 72 inch circle at the rating: a slab in full contact, per the concrete pad sizing guide, inside a berm or a containment tub sized to the tank; a 72 inch base fits a standard containment tub and stands without a strap on a flat slab. The tank sizing calculator sizes the tank to feed rate and delivery interval, and the tank sizing guide covers the reserve, which for hypochlorite is sized to turnover as much as to supply.
The opaque 1,300, and the sizes beside it
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1830400N52 (this tank, opaque, 1.9 SG) | 1,300 | 72 x 87 in | 320 lb |
| 1840400N52 (doorway, opaque, ASTM certified) | 1,500 | 60 x 137 in | 390 lb |
| 32531 (low profile, water) | 1,200 | 86 x 57 in | 169 lb |
The 1840400N52 is the other opaque tank, 1,500 gallons on a 60 inch base at 137 inches, certified, for a tank that has to come through a door and stand in a corner. The 32531 lays 1,200 gallons of water down under 57 inches on an 86 inch base for a site with floor and no height.
Need two of them? Request a written quote for the pair with freight to your ZIP, or call 866-418-1777 and we will price the truck once.
Ports and access
- Access: 18 inch threaded, vented manway, 87 inches up; vent outside on acid, caustic and hypochlorite service, fill through a dip tube, and size the vent for the delivery pump.
- Outlet: order the bulkhead fitting in the material the chemical calls for; a flanged transition and a valve supported off the floor, in the material the chemical calls for.
Choose the level sender for the chemical and read it at ground level; an opaque wall shows a shadow line in daylight, not a number. Keep the manway closed against vapor loss. Label it so the fire inspector and the workplace inspector read the same thing. In a cold climate the outlet valve and the first run of pipe are insulated or drained.
Receiving a delivery
A delivery truck's pump can push air out faster than a stock vent can pass it, so the vent is sized for the unload rate or the fill goes through a dedicated top bulkhead with its own vent line. A fill pipe to the floor keeps caustic or coagulant from free-falling and foaming. A dense liquid heats when water is added to it, so a batch tank is filled with water before the chemical, never after. The first load into a new tank gets watched end to end, eyes on the slab edge and the outlet fitting while the level comes up, and each delivery after it is logged with its date and strength; for hypochlorite the log is also the turnover schedule.
Typical duty
Hypochlorite and light-sensitive coagulants at a small plant, ferric and other dense coagulants under an eave with a containment tub, acid feed for pH control, and, with water in it, a cistern that stays clear or one cell of a small fire reserve of the kind the fire-water reservoir design guide describes. One chemical, one tank, one label that both inspectors read the same way.
Freight to your ZIP
The 1830400N52 ships palletized as LTL freight at a class rate; the freight cost estimator shows it for your ZIP, and the listed price is before freight. Two people stand 320 pounds; at 72 inches across it goes through a double door or outside. Water-fill it once to the manway, hold it, then drain and dry before the chemical connection is made. Photograph the outlet fitting from below before the pipe goes on; a slow weep is easier to compare against than to describe.
Freight and documents
Ships from: Chowchilla, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1830400N52.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
