Snyder Industries 15000 Gallon XLPE Black Heavy Duty Vertical Storage Tank

Where the cross-linked heavy wall earns its weight

Cross-linked polyethylene is the wall for chemistry that attacks or softens a linear wall and for liquids that arrive warm, and the heavy duty rating adds density. Buy this one when all three apply; buy a linear polyethylene heavy duty tank when the liquid is dense but cool and benign. Our guide to when cross-linking matters for chemistry duty works through the decision chemical by chemical. A rotationally moulded floor bears on its whole floor, so 237,690 lb lands on the 142 inch circle; engineer the slab to our concrete pad sizing guide, level and in full contact, inside containment sized to the tank. A warm liquid moves the wall more than a cold one, so keep the freeboard the tank sizing guide calls for, and check the volume against your draw in the tank sizing calculator. Band the empty shell to structure or to slab anchors before the first fill.

What to check before you buy

1. The liquid, its density and its temperature. 1.9 and 140 F are limits. Write all three next to the liquid's name on the wall, and tell us before you order if either is close.
2. The outlet. This page lists the manway, not a bottom fitting. Tell us the liquid and the draw-off arrangement and we will confirm what this tank accepts, in what material and with what gasket, before anything is drilled. Under 234 inches of dense liquid the base fitting sits on its own support off the pad with a flexible connector to hard pipe.
3. The manway. 18 inch threaded and vented, 234 inches above the pad: a fixed platform with a rail and a gate or a caged ladder to a landing, a permanent fill line landed at the manway, a dip tube to the floor, and the vent run outdoors on anything that fumes.

A black wall gives no level to read, so a sender with a readout at the ground is part of the install. Snyder's drawing for this tank is linked under Technical Drawing on this page.

Other walls in this size, and the sizes either side

Snyder makes this cross-linked tank in natural white heavy duty rated 1.9, part 5370000N42, and in standard walls rated 1.5 in black, part 5370000N46, and in natural white, part 5370000N40. Other 15,000 gallon Snyder tanks: the 15000 gallon black heavy duty tank 5370000C34, the 15000 gallon heavy duty tank 3030100C26 and the 15000 gallon vertical tank 3030100C37. Either side in volume, the 12500 gallon black heavy duty tank 5350000C34 is the step down and the 16500 gallon heavy duty tank 5380000C126 is the step up.

Shipping and receiving

The tank ships at freight class 250, 142 by 142 by 234 inches, 5,800 lb, from Snyder's plant at Lincoln, Nebraska, on an open deck as a permitted wide load. Price this lane on its own rather than assuming it from a sibling: put your ZIP into the freight cost estimator and walk the route in before the order. The listed price is before freight. Unload with a crane or a heavy forklift, straps under the body, never a sling through the manway. Check the part number against 5370000N48 on the bill of lading. Fill it with cold water to the manway before anything warm or dense goes in, and walk the base and the containment floor while it holds. Where a reuse train needs a bulk holding stage, our industrial water reuse tank topology article places a vessel this size; a private fire reserve is its own specification, as our fire water reservoir design guide explains.

Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
