Snyder Industries 200 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification

A day tank you can reach into, on a base that stands alone

An 18 inch manway on a 36 inch tank admits a fill hose, a float switch and a level sender at once, and a wash-down wand reaches every part of the floor at changeover; a 36 inch base under 53 inches stands without a bracket in most rooms. The wall is built for a liquid nearly twice the density of water and certified to ASTM D1998, the standard rotomolded polyethylene tanks are specified against; the HDPE tank wall thickness guide explains the D1998 sizing logic and why the vapor headspace is where a wall fails first, at any size. Full, it puts 3,169 pounds on a 36 inch circle, which a slab or a paver pad supports. The 200 gallon vertical tank buyers guide compares the shapes at this volume across makers; the tank sizing calculator sizes a day tank to the pump's rate and the refill schedule, and the tank sizing guide covers the reserve.

Snyder's 190 to 210 gallon verticals

The N42 is cross-linked polyethylene for hypochlorite and the other oxidizers, and the C26 and C34 are the general grades, all at this tank's weight in the same shell. The 1540400N42 lays 190 gallons down to 47 inches on a 42 inch base in cross-linked resin, and the 1012900C26 holds 210 gallons on this same 36 inch base 2 inches taller.

Settled on the 200 gallon tank? Freight to your ZIP and add to cart above; a written quote is one click away for the paperwork.

Fittings and access

• Access: 18 inch threaded, vented manway; filled by hose, drum pump or tote pump.
• Outlet: specify the bulkhead fitting for the chemical when ordering; a flexible line to the pump suction and a valve supported off the floor.
• Service limit: 120 F / 48 C.
• Listing: ASTM certification.

Put the dosing pump below the outlet, where it primes by gravity, with a union and a check valve in the suction line. A white 53 inch tank shows its level at a glance; a low-level float switch protects the pump. Keep the manway shut so nothing is lost as vapor, and shade the tank if the chemical is light-sensitive; a 36 inch tank fits a standard spill pallet.

Jobs it is bought for

Day tanks at small water systems and well houses, chemical feed skids, polymer make-down at a package plant, brine for a softener, and, with water in it, one cell of the small reserve the fire-water reservoir design guide describes. One chemical per tank, labeled, rinsed at every changeover through that wide manway.

What the carrier needs from you

The 1008000N45 ships palletized as LTL freight (NMFC 156600-02) at a class rate; the freight cost estimator gives the number for your ZIP; the price shown here is before freight. One person carries 65 pounds through a door. Check the manway and the outlet fitting, fill it once with water to prove the seal, and keep the certification paperwork with the project file. Note the pad height and the outlet height on the site plan while the tape is out; the next pipe run will need both.
