Snyder Industries 2000 Gallon Plastic Horizontal Leg Tank with Securing Hoops

Where it goes

This is the low, wide 2000 gallon nurse tank. At 84 inches wide it fills a flatbed deck side to side, and at 55 inches tall it keeps the centre of gravity low, which is what you want when the trailer is full and the field road is rough. Full of water it is more than eight tons, so the trailer's axle ratings and the tow vehicle decide whether it belongs there, not the tank. Set it with the weight over the axles, run the straps through the securing hoops rather than over the top opening, and re-tension after the first few miles. The legs need a flat, continuous deck for the full 142 by 84 inch footprint; on the ground, a level gravel or concrete pad under all the legs is enough. Our guide to applicator and leg tanks for fertilizer and the DOT non-roadable trailer rules explains when a nurse trailer counts as a cargo tank, and the farm fleet DOT classification guide covers the agricultural exemption.

What goes in it

Water and liquid fertilizer. The 1.5 rating is the thing to check: a 1.5 specific gravity rating means liquids up to one and a half times the weight of water, and most fertilizer solutions are inside that, but some concentrated salts and acids are not. If your product is heavier, ask us about the other versions of this tank, linked below. Check anything beyond fertilizer in our chemical compatibility guide; urea solution, calcium chloride and potassium hydroxide are the common questions at this size, and their weights matter here as much as their chemistry. Keep the liquid under 120 F. A nurse tank sits full for days and a blend separates in a still tank; our note on fertilizer blend stratification explains how to catch it. The tank sizing calculator and tank sizing guide will tell you how many sprayer fills 2000 gallons covers.

Openings and fittings

1. Outlet. 3 inch, which sets how fast you can load the sprayer. Match the valve, the camlock and the transfer pump to 3 inch rather than reducing. The thread form and fitting material are not listed on this page; ask us before you buy the valve.
2. Top opening. 18 inches: wide enough to fill from a pump discharge, to drop a float or a suction line in, and to get a head and shoulders in to inspect and clean. Confirm with us whether it ships as a lid or a manway before you buy a replacement cover.
3. Hoops. The securing hoops come with the tank. Strap through them, not over the shell.
4. Drawing. Snyder's drawing for this tank, linked under Technical Drawing on this page, shows the outlet position, the hoop positions and the leg layout.

Sizes nearby

Snyder makes this 2000 gallon tank with securing hoops in other versions: part number 1002300N45, the black version, part number 1002300N51, and part number 7510000C26 on a different mould. Compare the ratings, outlets and drawings on each page before you choose. One size down is the 1685 gallon leg tank; one size up is the 2600 gallon leg tank.

Shipping and receiving

The tank ships as oversize freight from the nearer of Snyder's plants at Chowchilla, California or Philippi, West Virginia, 142 by 84 by 55 inches at 700 lb, on a truck that needs room to turn and a forklift or a crew to unload. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 1002300C37 on the bill of lading, look at every leg, the hoops and the outlet boss for transit damage, and fill it with water the first time before it carries fertilizer.

Questions before you order? Call 866-418-1777.
