2,500 gallons in mocha, for the tank that should not be seen
The Snyder 32633 is a 2,500 gallon water tank in mocha brown high density linear polyethylene, 96 inches across and 90 inches tall, weighing 343 pounds. Mocha is the color for a tank beside a house, a barn or a fence line where black would shout and green would clash with a painted wall; it blocks light like both, so the water stays clear. A 26 inch manway, threaded polypropylene fittings, a heavier wall than the 300 pound tanks in the same mold, and a rating of 1.0 specific gravity for water and liquids no heavier.
Two ways to buy. Add it to your cart above with freight quoted to your ZIP, or request a written quote for a job that needs paperwork.
Base and setting
Full, the 32633 puts 20,850 pounds on a 96 inch circle: a slab or a compacted pad in full contact with the whole floor, sized by the ACI 360R-10 method in the concrete pad sizing guide. At 90 inches it sits below the eave of most outbuildings and disappears against siding or bare earth. Leave room above the manway for the lid and a hose, and a clear side for the outlet and a pump. The tank sizing calculator confirms 2,500 gallons against your draw.
Colors and walls on the 96 x 90 inch mold
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32633 (this tank, mocha) | 2,500 | 96 x 90 in | 343 lb |
| 32559, black | 2,500 | 96 x 90 in | 343 lb |
| 32747 | 2,500 | 96 x 90 in | 300 lb |
| WG62, green | 2,600 | 96 x 91 in | 427 lb |
| 32553 | 2,000 | 96 x 73 in | 263 lb |
The 32633 and the black 32559 are the same heavy-wall tank in two colors, 43 pounds more resin than the standard 32747. The green WG62 is heavier still at 427 pounds, with a stainless bolted outlet and 100 more gallons. The 32553 is the short tank on this base, 17 inches lower for 500 fewer gallons. Color is the only thing that separates the first two rows; buy by what the tank stands next to.
Not sure which one? Tell us the liquid, the site and the ceiling height at 866-418-1777, or request a written quote with freight to your ZIP.
Ports
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting at the base.
- Access: 26 inch threaded, vented manway.
- Service limit: 120 F / 48 C.
A 26 inch manway takes a float valve, a level sender and a wash-down wand together, and 90 inches of head over the 2 inch outlet gravity-feeds a trough line. Mocha is as opaque as black; a sight tube off the outlet reads the level. Brown absorbs a little less heat than black in full sun, and like every dark tank it warms stored water on a summer afternoon, so draw from the outlet at the base where the water stays coolest and shade the tank where the site allows. Clean it once a year through the manway with a wash-down wand, drain through the outlet, and let it dry before refilling; a screen on the inlet and the vent keeps leaves and insects out between cleanings.
Where you will find one
Beside a house as a whole-property rain cistern, at a ranch as stock water, and as the fire reserve a rural fire district asks for, sized under NFPA 22 per the fire-water reservoir design guide. The tank sizing guide turns 2,500 gallons into days of supply for a household or a herd.
Getting it to the pad
At 96 inches across the 32633 is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. A forklift with long forks or four people set 343 pounds on the pad. Strap it while empty, then fill in stages with the pad and both fittings under watch, per the hydrostatic test methodology guide. Mark the vent and the outlet on the outside of the shell so nobody caps the wrong one in the dark.
Freight and documents
Ships from: Albertville, AL. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32633.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Ready to order?
Add it to your cart at the top of this page, get LTL freight to your ZIP, request a written quote, or call 866-418-1777. The listed price is before freight.
