Snyder Industries 360 Gallon Plastic Vertical Double Wall Liquid Chemical Storage Tank

The biggest day tank that still fits under a mezzanine

Three hundred sixty gallons is a tote and a half, drawn down by a dosing pump over a week or two, and this shape holds it at 63 inches, so it goes under a mezzanine or a low pipe rack where a tall tank of the same volume would not. With the containment between the walls, a leak never reaches the floor, and neither a spill pallet nor a berm is needed; the SPCC 40 CFR 112 compliance walkthrough covers where a double wall tank satisfies a spill plan on its own, and the Captor double wall freeboard sizing guide works out how much of the nominal 360 gallons is usable once thermal expansion and the interstice are accounted for. The chemistry list below is what the resin is rated for; check the liquid at its concentration in the chemical compatibility database. The tank sizing calculator sizes the tank to feed rate and delivery interval, and the tank sizing guide covers the reserve.

Grades on the 53 x 63 inch double wall, and the sizes beside it

The N30 is the sulfuric acid grade, the N42 is cross-linked polyethylene for oxidizers, and the N48 is another linear grade, all at the same weight in the same shell. The 5740102N30 is the 275 gallon double wall at the same 63 inch height on a base 6 inches narrower, and the 5990702N45 stands 405 gallons 10 inches taller on a 48 inch base for the corner with height and no floor.

Need a different size? Every tank in the table is in stock programs; ask for a quote on the one that fits, or call 866-418-1777.

Connections, alarms and the interstitial check

• Access: 18 inch threaded, vented manway on the primary, at chest height; fill by hose or tote pump down a dip tube, and vent to the outside if the liquid fumes.
• Outlet: through both walls together, with the transition supported off the floor; the fitting material is chosen for the chemical at order time.
• Service limit: 120 F / 48 C.

There are two levels to watch: the primary, with a sender chosen for the chemical per the level gauge selection guide, and the interstitial space, which is the leak alarm and gets a float switch and a logged check. A tank filled from totes is also where overfills happen, because a tote pump runs until someone stops it; the tank spillover redundancy guide covers the high-level alarm and automatic cutoff that stop a release before the containment has to catch it. A low tank cannot tip and needs no strap; mount the dosing pump below the outlet so it primes by gravity, and give the vent a line routed away from the pump's electrical gear. Full, it puts 5,705 pounds on a 53 inch circle at the rating; a slab in full contact carries that.

Turnover and changeover

Size the refill schedule so the tank turns over before the chemical degrades; hypochlorite in particular is bought in small lots often. At changeover the low shape earns its keep: the manway is at chest height and the floor is a hand's reach through it, so a wash-down wand cleans the primary without anyone leaning over an opening. Drain, rinse, drain again, let it dry before the new fill, and log each fill with its date and strength.

Where you will find one

Coagulant, caustic and hypochlorite day tanks inside occupied buildings with a low ceiling, acid and inhibitor feed at cooling towers, polymer make-down on a skid, and any small regulated chemical tank at a site an inspector visits. Label it, keep one chemical in it, and keep the manway shut against vapor loss.

Compatibility list

Liquids the maker rates this resin for, with concentration limits and the wetted fitting and gasket to specify. Confirm your own concentration and temperature on the chemical page or in the chemical compatibility database before ordering.

• Acetic Acid (60%) - PP/PVC fittings, EPDM gaskets
• Aluminum Sulfate (50%) - PVC fittings, EPDM gaskets
• Calcium Chloride (40%) - PVC fittings, EPDM gaskets
• DEF (32.5%) - 316SS fittings, EPDM gaskets
• Ethylene Glycol (100%) - PVC fittings, EPDM gaskets
• Ferric Chloride (50%) - PVC fittings, EPDM gaskets
• Hydrochloric Acid (37%) - PVC fittings, Viton gaskets
• Hydrofluoric Acid (48%) - PP/PVC fittings, Viton gaskets
• Hydrofluosilicic Acid (26%) - PP/PVC fittings, Viton gaskets
• Hydrogen Peroxide (50%) - PVC fittings, Viton gaskets
• Phosphoric Acid (85%) - PVC fittings, Viton gaskets
• Peracetic Acid (30%) - 316SS fittings, Aflas gaskets
• Potassium Hydroxide (Saturated) - PVC fittings, EPDM gaskets
• Sodium Hypochlorite (under 16.5%) - PVC fittings, Viton gaskets
• Sodium Carbonate (30%) - PVC fittings, EPDM gaskets
• Sulfuric Acid (98%) - CPVC fittings, Viton gaskets
• Urea Solution (50%) - PP/PVC fittings, EPDM gaskets
• Ferric Sulfate (60%)
• Ferrous Sulfate (20%)
• Magnesium Chloride (30%)
• Potassium Carbonate (50%)
• Sodium Thiosulfate (40%) - PVC fittings, EPDM gaskets
• Polyaluminum Chloride
• Sodium Bisulfate
• Sodium Bisulfite
• Zinc Orthophosphate
• Propylene Glycol - confirm concentration for your service

Shipping the tank

The 5760102N45 ships palletized as LTL freight (NMFC 156600-03) at a class rate; the freight cost estimator turns your ZIP into a freight number; the price on this page is before freight. A pallet jack moves 250 pounds; two people can walk it off the pallet. Water-test the primary, confirm the interstice stays dry through the hold, then drain and dry before the first chemical fill. Walk the base after the first hard rain; a pad that shifts shows it at the edge first.
