13000 Gallon Vertical Liquid Storage Tank

Where it goes

A twelve foot circle under sixteen and a half feet of tank is a permanent installation, not something you move next season. It serves as a dairy, feedlot or ranch water supply, a bulk fertilizer or crop protection tank at a dealer or a large farm, a process or reuse buffer at a plant, and a rural fire reserve. Full of water the floor carries 108420 lb of liquid plus the tank, so the pad is engineering, not landscaping: level, continuous, carrying the whole 144 inch floor with nothing past the edge, designed with our concrete pad sizing guide. The manway needs a fixed ladder or a platform, and everything overhead needs checking before the truck comes. For a fire reserve, the fire water reservoir design guide covers sizing discipline and freeze protection; for rainwater and reuse, the industrial water reuse topology guide shows where a tank this size sits in the train. The complete buyers guide to this tank goes deeper, and the tank sizing calculator and tank sizing guide settle the volume first.

Openings and fittings

1. Outlet. A 3 inch 316 stainless steel female NPT bolted fitting, factory installed low in the side wall. A bolted fitting clamps the wall between two flanges rather than relying on a single nut, which is why Norwesco uses it on the biggest tanks, where the wall is thickest and the head of liquid is highest. Your 3 inch valve threads straight in. Support the valve and the first run of pipe on their own; a steel valve on a 3 inch port is heavier than it looks.
2. Manway. A 22 inch threaded vented manway on top, 198 inches up: fill point, vent and a wide opening for a pump drop, a float or a cleaning crew's gear.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and manway position for your layout.
4. Liquid. Water and most liquid fertilizers sit inside the 1.5 specific gravity rating. For heavier liquids Norwesco makes a 1.9 rated version of this shell, listed below. If the liquid is anything other than water or a common fertilizer, tell us what it is so we can check it against both the polyethylene and the stainless fitting.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 13000 gallon black vertical tank 44386. Same shell rated for liquids up to 1.9 specific gravity: the 13000 gallon blue heavy duty vertical tank 44017 and the 13000 gallon black heavy duty vertical tank 44017B. One size down, barely narrower and barely shorter: the 12000 gallon black vertical tank 40874. One size up, wider and a little shorter: the 15000 gallon black vertical tank 43821B. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from Norwesco's Albertville, Alabama plant, 198 by 144 by 144 inches lying down on the truck and 2713 lb. It travels on an open trailer and needs a forklift or a loader with forks rated for the weight, a crew with straps, and room to stand a sixteen foot tank up beside its pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 44015 on the bill of lading, look over the shell and the stainless fitting for transit damage before you sign, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
