200 Gallon Vertical Liquid Storage Tank

Where it goes

Two hundred gallons on a 30 inch circle is the size where a vertical tank stops being a drum replacement and starts being a supply: a make-up or chemical feed tank in a plant room, a rinse tank on a wash bay, a water or fertilizer tank in a barn or greenhouse, a holding tank in a well house, or a rainwater tank beside a shop. The height is the number to check: 72 inches to the top of the tank plus room for the lid and a hose, measured to the lowest duct, light or header over the spot. The lid is above head height for most people, so plan a fill line or a pump, and a float or a sight line for the level. Thirty inches is a few inches wider than a standard doorway; most double doors and every roll-up door take it upright. A tall tank wants a level floor. Full of water it puts about 1670 lb on a 30 inch circle, and a rotationally moulded base bears on everything it touches and nothing else, so it needs a flat, continuous surface under the whole base.

What goes in it

Water, liquid fertilizer, wash water and the treatment chemicals that polyethylene handles are the normal loads. Liquids heavier than 1.5 times water belong in a heavy duty tank rated 1.9; the 175 gallon heavy duty vertical tank is the nearest. Keep the contents under 120 F. White shows the level against light behind the tank; black keeps light out and slows algae in stored water. Our buyer's guide to the 200 gallon vertical tank, part number 41856 is written around this exact tank, and the tank sizing calculator and tank sizing guide settle whether 200 gallons is the right number.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 2 inch ball valve, camlock or hose adapter threads straight in. Dry-fit the valve so the handle clears the wall, seal the threads, and support the valve and the first length of pipe on their own; a 2 inch valve with a hose on it is more weight than a tank wall should carry.
2. Lid. An 8 inch threaded vented lid. Wide enough for a hose, a float switch or a small pump inlet; the vent lets air in as the tank drains so the walls are never pulled inward. Fit the float and the fill line before the tank is in its corner, while you can still reach the top from a step.
3. Drawing. Norwesco's drawing for this tank is linked on this page under Technical Drawing. It gives the outlet height and the lid position for planning the pipe run.

Sizes nearby

Norwesco makes 200 gallons in three shapes. This one and the 200 gallon vertical tank, part number 41516, share the 30 by 72 inch footprint; the 200 gallon vertical tank, part number 41518 is the shorter, wider one, with its own buyer's guide. In black: the 200 gallon black vertical storage tank and, one size up, the 210 gallon black vertical storage tank. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL from the nearest of Norwesco's plants, 30 by 30 by 72 inches on a pallet at a ship weight of 54 lb. Norwesco makes it at Burnet and Fairfield, Texas, Griffin, Georgia, Hanford, California, Lancaster, Ohio, Owego, New York, Shawnee, Oklahoma, Sheldon, Iowa, St. Bonifacius, Minnesota, Tooele, Utah and Washougal, Washington. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number 41856 on the bill of lading, look at the base and the 2 inch fitting before the driver leaves, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
