5000 Gallon Vertical Liquid Storage Tank

Where a wide, low five thousand earns its place

This is the tank for a site with a height limit: inside a pole barn, under a roof overhang, behind a fence line that must not be seen over, or where a forklift has to set it in place through a door. The cost of the low profile is the pad: a flat, continuous, level surface at least 141 inches across under the whole floor, with no edge of the base hanging past the slab or the gravel. Our complete buyers guide to this shell walks through pad, overflow and venting choices. Full of water it puts 41700 lb of liquid plus the tank's own 854 lb on that pad, so a compacted gravel bed or a slab, not bare dirt, is the right base. If the volume is still open, the tank sizing calculator and the tank sizing guide get you to a number before you commit to a footprint.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a siphon tube inside the tank. The siphon tube lets a side outlet draw the tank down close to the floor instead of leaving the last few inches below the fitting. Your 3 inch valve threads straight in; support the valve and the first run of pipe so the wall carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top. It is the fill point, the vent and the way in for cleaning, and on a tank only 86 inches tall it is a short step ladder away.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height, the manway position and the overall envelope for your pad and pipe layout.
4. Liquid. The 1.5 specific gravity rating covers water and most liquid fertilizers. Anything heavier, or a liquid that attacks polyethylene, needs a different tank; tell us what is going in and we will say which one.

Sizes nearby

Same shell in black, for water you want to keep algae out of: the 5000 gallon black vertical tank 40941B. If you have the height and want a smaller footprint, the narrow and tall five thousands are the 5000 gallon black vertical tank 40164B and its heavy duty twin, the 5000 gallon black heavy duty vertical tank 40166B. For liquids heavier than 1.5 specific gravity on this same wide shell, Norwesco makes a 1.9 rated version: the 5000 gallon heavy duty vertical tank 43833 in blue and the 43833B in black. Slightly smaller on a wide base: the 4995 gallon black vertical tank 44822B. One step up in gallons, much taller: the 6000 gallon black vertical tank 40769. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from Norwesco's Hanford, California plant, 141 by 141 by 86 inches and 855 lb on the truck. It travels on an open trailer, so plan on a forklift or a crew with straps and a clear path to the pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 40941 on the bill of lading, walk round the shell for transit damage, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
