5000 Gallon Blue Heavy Duty Vertical Liquid Storage Tank (141" x 86")

Who buys the short 5000

Buy this tank when two things are true at once: the liquid is heavier than water, and the space is short. At 86 inches tall it goes inside a building, under a canopy or beside a loading dock where the tall 5000 gallon verticals cannot stand, and it fills from a short step ladder. The price of the height is floor: it needs a flat, continuous 141 inch circle of pad, which is nearly twelve feet across. Full of a 1.9 liquid that pad carries a heavy, concentrated load, so size the slab to the tank, not to the floor around it. If your liquid is water or close to it, the standard rated version holds the same 5000 gallons for less; the heavy duty rating is what you are paying for here. Our complete buyer's guide to the 141 by 86 inch 5000 gallon vertical walks through the rest of the decision.

What goes in it

Dense liquid fertilizer and water treatment chemicals are the usual loads, with water behind them. Check the liquid in our chemical compatibility guide before the first fill and keep the contents under 120 F. A wide, low tank has a large liquid surface and a correspondingly large vapour space above it, which is where polyethylene sees its harshest exposure with aggressive chemicals; our note on wall thickness at the vapour saturated headspace explains what to inspect and when. For a rural water or fire reserve, our guide to fire water reservoir design for rural and remote sites covers sizing and freeze protection. For the volume itself, use the tank sizing calculator and the tank sizing guide.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a siphon tube so the tank draws from the bottom. A 3 inch valve or camlock threads straight in. Support the valve and the first length of pipe so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top: wide enough to fill from a hose or a pump, drop a float or a level sensor in, and get a brush inside. On this tank the manway is within reach from a step ladder.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height and the manway position for piping layout.

Same tank in other colours and ratings, and the tall 5000s

This short body also comes as the 5000 gallon black heavy duty vertical tank, and in the standard 1.5 rating as the 5000 gallon white vertical tank and the 5000 gallon black vertical tank. If you have the height, the tall 5000 gallon verticals take less floor: the 5000 gallon black heavy duty vertical, the 5000 gallon black vertical and the 4995 gallon black vertical. One size up: the 6000 gallon black vertical tank. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight, Norwesco's OVS class, 141 by 141 by 86 inches, from Norwesco's Hanford, California plant; Norwesco gives the ship weight as 1015 lb. A load nearly twelve feet wide needs a route check and a wide spot to unload, so tell us about gates and overhead lines when you order. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. Have a loader on site. At the tailgate, check the part number against 43833 on the bill of lading and look over the whole shell for transit damage. Set it on the finished pad, fit the outlet valve before the first fill, and fill with water the first time so any problem shows up with something harmless in the tank.

Questions before you order? Call 866-418-1777.
