8400 Gallon Vertical Liquid Storage Tank

Where it goes

Pick this shell when the ground is fixed at ten feet and the sky is open. It is a serious reserve: a ranch that hauls water, a grower with a long irrigation set, a rural property that wants a fire reserve on site, a shop or plant that buffers process water. Fifteen and a half feet of tank changes the job of setting it: the pad must be level, continuous and carry the whole floor, with nothing hanging past the edge, and full of water the floor carries 70056 lb of liquid plus the tank, so a slab or a contained, compacted gravel bed is the base. The manway is a fixed ladder or platform job, not a stepladder one, so place the tank where that can be built safely. Our complete buyers guide to this tank covers the pad, overflow and venting details, and the guide to the wider 8400 explains when Norwesco's other 8400 shell is the better pick. The tank sizing calculator and tank sizing guide settle the volume first.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a 2 inch reducer in it. Connect 2 inch as supplied, or take the reducer out for the full 3 inch port and a faster drain. Match the valve to that choice, and support the valve and the first run of pipe so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top, 188 inches up: fill point, vent and inspection opening.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and manway position for your pipe layout.
4. Liquid. Water and most liquid fertilizers sit inside the 1.5 specific gravity rating. For heavier liquids Norwesco makes a 1.9 rated version of this shell, listed below. Tell us what is going in and we will confirm the material suits it.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 8400 gallon black vertical tank 42060B. Same shell rated for liquids up to 1.9 specific gravity: the 8400 gallon blue heavy duty vertical tank 42062 and the 8400 gallon black heavy duty vertical tank 42062B. The same gallons on a slightly wider, slightly shorter shell from the southern plants: the 8400 gallon black vertical tank 44395B. One size down on the same footprint: the 7800 gallon black heavy duty vertical tank 42883. One size up, wide and squat: the 9000 gallon black vertical tank 40786. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from Norwesco's Hanford, California plant, 188 by 119 by 119 inches lying down on the truck and 1717 lb. It travels on an open trailer, so plan on a forklift, a loader with forks or a crew with straps, and room to stand a fifteen foot tank up beside its pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 42060 on the bill of lading, look over the shell for transit damage before you sign, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
