An 8400 gallon blue heavy duty vertical tank with a siphon tube on the outlet
The Norwesco 8400 gallon heavy duty vertical liquid storage tank, part number 44397, is a blue polyethylene tank 120 inches in diameter and 187 inches tall, weighing 1960 lb empty. It is the heavy duty version of Norwesco's 8400 gallon vertical: rated for liquids up to 1.9 specific gravity, so it stores dense fertilizer solutions and the heavier chemicals that a standard water tank is not built for. 8400 gallons of water weighs 70056 lb and the rating allows contents up to 133106 lb. It comes with a 3 inch polypropylene female NPT bulkhead fitting with a 2 inch reducer and a siphon tube as the outlet, and a 16 inch threaded vented manway on top. The siphon tube draws from inside the tank, which keeps the outlet fitting above the sediment line; it is the arrangement fertilizer dealers ask for. Norwesco backs it with a 3 year limited full replacement warranty per its 2024 liquid storage catalog, and the service limit is 120 F.
Is this the right size? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with what you are storing and where.
Where it goes
A vertical tank stands on its own flat bottom, so the pad is the installation. It needs a flat, level, continuous surface at least 120 inches across with no gravel points, drain or slope under it; full of water this tank is a concentrated load of better than 70100 lb on that circle, and much more at the full 1.9 rating. At this size the pad, the tie-downs and the wind load are an engineering question: our guide to concrete pad sizing for above ground polyethylene tanks covers the pad. Check overhead clearance for the truck that delivers it and for anyone who will open the manway. The 8400 gallon vertical tank buyer's guide walks through the whole decision for this footprint.
What goes in it
Liquid fertilizer is what most buyers put in a heavy duty vertical with a siphon outlet, with water and the farm and treatment chemicals that polyethylene handles behind it. The 1.9 rating is the reason to pick this tank over the standard one: if the liquid is heavier than water, you want this wall thickness. Before anything new goes in, check the liquid in our chemical compatibility guide. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting with a 2 inch reducer and a siphon tube, factory installed. Run 3 inch plumbing off it for a fast transfer pump, or leave the reducer in and run 2 inch. A siphon outlet needs the pump to be primed or the line to be flooded before it will draw; plan the pump for that. Support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
- Inlet. None is fitted. Fill through the manway, or tell us where you want a fill port and we will talk through the options before the order ships.
- Manway. A 16 inch threaded vented manway on top, 187 inches up, so plan a ladder or a platform to reach it. The vent is what lets the tank breathe as it fills and empties; never seal it.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the exact outlet height, the siphon arrangement and the manway position.
Sizes and colours nearby
Same heavy duty tank in black, for water you want kept dark: the 8400 gallon black heavy duty vertical tank. For water and lighter liquids, the standard duty versions: the 8400 gallon black vertical tank 44395B and the 8400 gallon black vertical tank 42060B. One size down: the 7800 gallon black heavy duty vertical tank. One size up: the 9000 gallon black vertical tank.
Shipping and receiving
The tank ships as an oversize load from Norwesco's Albertville, Alabama or Fairfield, Texas plant, whichever is nearer, 187 by 120 by 120 inches on its side and 1960 lb, on a flatbed or a tank trailer. You need room for a long truck to get in and turn, and a loader, a telehandler or a crew to roll it off and stand it up on the pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 44397 on the bill of lading, look at the bottom edge and the outlet for transit damage, and fill it with water the first time before it holds anything else.
Questions before you order? Call 866-418-1777, or request a written quote for a job that needs paperwork.
Freight and documents
Ships from: Albertville, AL; Fairfield, TX. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44397.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 8400 Gallon Blue Heavy Duty Vertical Liquid Storage Tank video (62 seconds) with dimensions, fittings and shipping notes.
