1,300 gallons on a 60 inch circle
The Snyder 32535 is the tall, narrow way to store 1,300 gallons: 60 inches across, 114 inches high, black polyethylene, 194 pounds empty. It exists for the site that has a 5 foot corner and a high ceiling, and nothing else in the Snyder line puts this much water on this little floor. A 20 inch threaded vented manway on top, 1-1/2 inch polypropylene inlet, 2 inch polypropylene outlet, rated for a specific gravity of 1.0.
Ready to price it? The listed price is before freight; quote freight to your ZIP in a few seconds, then add to cart above or call 866-418-1777.
What a 114 inch tank asks of the installer
Nine and a half feet of tank means a ladder to open the manway, an overhead clearance check before delivery, and a base that is dead level, because a tall narrow tank carries its 10,842 pound full weight high and a tilt of an inch at the floor becomes several at the rim. Pour or set a level pad in full contact with the whole 60 inch floor; the concrete pad sizing guide covers the ACI 360R-10 method. Plumb the fill to the top inlet so the manway stays closed, and keep its vent clear: a pump drawing 1,300 gallons down through a 2 inch outlet moves a lot of air.
Against the low tanks
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| WB42 | 1,100 | 86 x 53 in | 210 lb |
| 32535 (this tank) | 1,300 | 60 x 114 in | 194 lb |
| 32537, green | 1,300 | 60 x 114 in | 194 lb |
| 32541 | 1,500 | 65 x 114 in | 230 lb |
The WB42 is the opposite answer: 200 fewer gallons on a floor 26 inches wider and 61 inches lower. The 32541 is the next step up on the same height, 5 inches wider for 200 more gallons and 36 more pounds of wall. The green 32537 is this exact tank for potable water in the open. If the corner is tight but the ceiling is not, this shape wins; if the ceiling is the problem, nothing in the narrow family helps and the low WB42 is the answer.
Want us to check the fit? Send the site dimensions to 866-418-1777 or through a written quote request and we will confirm the tank, the pad and the freight.
Connections
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting; valve, then union, then pump.
- Access: 20 inch threaded, vented manway.
- Service limit: 120 F / 48 C.
Put a full-port valve on the outlet first and a union between valve and pump, so the pump comes off without draining 1,300 gallons; run the fill line to the top inlet with a float valve, and keep the manway for inspection only.
A sight tube on the outlet reads the level through the black wall; for an automated fill the level gauge selection guide compares sensors.
Thirteen hundred gallons
A well reserve for a household, a rainwater store beside a two-story wall, wash water for a shop with a tall bay, and the first block of a fire reserve sized with the fire-water reservoir design guide. In a reuse train it is the collection tank ahead of treatment, per the industrial water reuse topology guide. Check the days of supply with the tank sizing calculator and the tank sizing guide.
Freight
LTL freight, NMFC 156600-01, 194 pounds crated at 60 by 60 by 114 inches, which ships lying down; the freight cost estimator quotes your ZIP and the listed price is before freight. Two people stand it up. First fill in stages, watching the base as the column loads it, per the hydrostatic test methodology guide.
Freight and documents
Ships from: Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32535.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
