2000 Gallon Vertical Liquid Storage Tank

Where a tall, narrow tank earns its place

Most 2000 gallon vertical tanks are seven to eight feet across. This one is a little over five feet across and almost thirteen feet tall, so it goes where the others cannot: beside a building, in the corner of a wash bay, between two pieces of equipment, or through a gate that a wider shell would never clear. The trade is height. Measure the clear height at the final position and at the lowest point on the path in, because a tank that fits where it stands but not where it has to pass is no use. Add room above the manway for a fill hose or a float switch. A tall, narrow shell also catches wind and has a smaller footprint to resist it, so plan to strap it to a wall, a frame or ground anchors before the first fill. If you have the floor space, the wider 2000 gallon shells are easier to live with; the buyer's guides to the first wide 2000 gallon shell and the second sit beside the guide to this tank so you can compare them. For the volume itself, the tank sizing calculator and tank sizing guide turn your draw and refill interval into a size.

Openings, fittings and the pad

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. Your valve or hose adapter threads straight in. Support the valve and the first length of pipe so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top. It takes a fill hose, a float, and a hand with a brush for cleaning. The vent is what lets the tank breathe as it fills and drains; never plug it.
3. The pad. A rotationally moulded floor bears on everything it touches and nothing else. Give the whole 64 inch circle continuous contact: a level slab, a steel plate or a compacted, screeded bed with a retained edge. No rails, no pallet, no shim under one side.
4. The liquid. Polyethylene suits water, most fertilizers and many common chemicals, up to 1.5 specific gravity and 120 F. Anything heavier needs the heavy duty version of a 2000 gallon tank, linked below.
5. Drawing. Norwesco's drawing for this tank is linked under Technical Drawing on this page and shows the outlet height and manway position.

Sizes and versions nearby

Same capacity in black, which keeps light out and slows algae in stored water: the 2000 gallon black vertical tank. For liquids heavier than 1.5 times water, the 1.9 rated versions: the 2000 gallon light blue heavy duty tank and the 2000 gallon black heavy duty tank. One step down: the 1700 gallon black vertical tank. One step up: the 2100 gallon black vertical tank.

Shipping and receiving

The tank is an oversize LTL load, 154 by 64 by 64 inches lying down on the trailer and 300 lb, and it ships from Norwesco's Burnet, Texas plant, which makes Texas and the states around it the short lane. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number 41511 against the bill of lading, walk round the shell for transit damage before the driver leaves, stand it with the outlet pointing where the pipe will run, and fill it with water the first time so any problem shows up with something harmless in it.

Questions before you order? Call 866-418-1777.
