7800 Gallon Vertical Liquid Storage Tank

Where it goes

Nearly fifteen feet tall and ten across, this tank wants open sky or a tall structure and a pad that carries the whole floor. It is the size a ranch buys when one fill has to last through a dry month, a grower buys for fertilizer or irrigation buffer, and a rural property buys as a private fire reserve; the fire water reservoir design guide covers that use and what cold weather does to it. Rainwater and reuse systems are in the industrial water reuse topology guide. For the pad, read the concrete pad sizing guide: full of water the floor carries 65052 lb of liquid plus the tank, and every part of the base must be on the slab or the contained gravel, with nothing hanging past the edge. The complete buyers guide to this tank goes deeper, and the tank sizing calculator and tank sizing guide settle the volume first.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a 2 inch reducer in it. Connect 2 inch as supplied, or remove the reducer for the full 3 inch port and a faster drain. Decide before you buy the valve, and support the valve and the first run of pipe so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top, 176 inches up: fill point, vent and inspection opening. Plan a fixed ladder or a platform.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and manway position for your layout.
4. Liquid. Water and most liquid fertilizers sit inside the 1.5 specific gravity rating. For heavier liquids Norwesco makes a 1.9 rated version of this shell, listed below. Tell us what is going in and we will confirm the material suits it.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 7800 gallon black vertical tank 41301. Same shell rated for liquids up to 1.9 specific gravity: the 7800 gallon blue heavy duty vertical tank 40665 and the 7800 gallon black heavy duty vertical tank 42883. One size down on a narrower, taller shell: the 6502 gallon black heavy duty vertical tank 47620B. One size up on the same ten foot footprint: the 8400 gallon black vertical tank 42060B. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from the nearer of Norwesco's Hanford, California and St. Bonifacius, Minnesota plants, 176 by 119 by 119 inches lying down on the truck and 1527 lb. It travels on an open trailer, so plan on a forklift, a loader with forks or a crew with straps, and room to stand it up beside the pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 40663 on the bill of lading, look over the shell for transit damage before you sign, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
