A 150 gallon certified tank on a 34 inch base
The Snyder 5710100N45 is a small vertical liquid storage tank: 150 gallons of white polyethylene in a shell 34 inches across and 61 inches tall, weighing 58 pounds. It carries the same 1.9 specific gravity wall as the big chemical tanks, rated for 2,377 pounds of contents against 1,251 for water, and it is sold with ASTM certification for the skid or the lab where the paperwork has to match the plant's. A 14 inch manway on top, a 3 year warranty, and it ships as small LTL freight.
Want it on the pad this month? Check freight to your ZIP, add it to your cart above, and 866-418-1777 will confirm the ship date.
The wider-based 150
Snyder makes two certified 150 gallon tanks; this is the one on the 34 inch base, wide enough to stand without a bracket in most rooms, with a 14 inch manway that takes a fill hose and a float switch at once. The wall is sized for a liquid nearly twice as dense as water and certified against ASTM D1998, the standard rotationally molded polyethylene tanks are specified to; the HDPE tank wall thickness guide explains the D1998 sizing logic and why the vapor headspace is where a wall fails first, and the freeboard sizing guide works out how much of the nominal 150 gallons is usable once thermal expansion is accounted for. Full, it puts 2,377 pounds on a 34 inch circle, which a slab or a paver pad supports. The tank sizing calculator sizes a day tank to the pump's rate and the refill schedule, and the tank sizing guide covers the reserve.
Snyder's 130 to 175 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 5710100N45 (this tank, ASTM certified) | 150 | 34 x 61 in | 58 lb |
| 1012800N45 (ASTM certified, 18 inch manway) | 150 | 30 x 59 in | 55 lb |
| 1012800N42 (XLPE) | 150 | 30 x 59 in | 55 lb |
| 1012800C34 | 150 | 30 x 59 in | 55 lb |
| 1009500N45 (ASTM certified) | 130 | 29 x 49 in | 50 lb |
| 1008400C26 | 175 | 29 x 66 in | 60 lb |
The 1012800 tanks are the narrower 150s on a 30 inch base, the N45 certified with an 18 inch manway, the N42 in cross-linked resin for oxidizers, the C34 in the general grade. The 1009500N45 is the certified 130, 12 inches shorter, and the 1008400C26 holds 175 gallons on a 29 inch base 5 inches taller.
Need a different size? Every tank in the table is in stock programs; ask for a quote on the one that fits, or call 866-418-1777.
Ports
- Access: 14 inch manway; filled by hose, drum pump or tote pump.
- Outlet: tell us the chemical when ordering and the bulkhead fitting is matched to it; a flexible line to the pump suction and a valve supported off the floor.
- Service limit: 120 F / 48 C.
- Listing: ASTM certification.
Set the dosing pump lower than the outlet so gravity primes it, with a union and a check valve in the suction line, and bracket the tank anyway where a hose could snag it. A white 61 inch tank shows its level at a glance; a low-level float switch protects the pump. Keep the manway closed against vapor loss and the tank out of direct sun where the chemical is light-sensitive; a 34 inch tank fits a standard spill pallet.
Where you will find one
Day tanks at small water systems and well houses, chemical feed skids, lab and pilot plants, brine for a small softener, and the bench reservoir that feeds a metering pump for a test. Label it, keep one chemical in it, and rinse it at every changeover.
Shipping the tank
The 5710100N45 ships palletized as LTL freight (NMFC 156600-01) at a class rate; the freight cost estimator turns your ZIP into a freight number; the price on this page is before freight. One person carries 58 pounds. Check the manway and the outlet fitting, fill it once with water to prove the seal, and keep the certification paperwork with the project file. Walk the base after the first hard rain; a pad that shifts shows it at the edge first.
Freight and documents
Ships from: Marked Tree, AR. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5710100N45.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
