3,000 gallons of black water storage on a 90 inch base
The Snyder WB70P is a black polyethylene water tank that holds 3,000 gallons in a shell 90 inches across and 125 inches tall, weighing 430 pounds. It is the tank for water in full sun: the black wall keeps light out so the water stays clear of algae, and the 90 inch base puts a tanker's partial load under a ten and a half foot roof. A 1-1/2 inch polypropylene female NPT bulkhead inlet, a 2 inch polypropylene female NPT bulkhead outlet, an 18 inch threaded, vented manway, a 3 year warranty, and a rating of 1.0 specific gravity for water and liquids no heavier.
Need the certification on file? Add the 3000 gallon tank to your cart above with freight quoted to your ZIP, or call 866-418-1777 and the paperwork ships with the tank.
Twelve and a half tons of water on a seven and a half foot circle
Full, the WB70P puts 25,020 pounds on a 90 inch circle, and a rotationally molded floor bears on the whole pad, so the pad is what matters: a compacted, screeded gravel base or a slab in full contact, with the empty tank strapped against wind, because a black tank in the sun expands and moves a little every day. Black polyethylene absorbs the ultraviolet that ages a white wall and passes no light to the liquid, so a black tank outdoors holds water clear for years; it also runs warmer than a white one, which matters for drinking water in a hot climate. Two of our buyers guides cover this volume in other makers' black water tanks, the first 3,000 gallon black water tank buyers guide and the second 3,000 gallon black water tank buyers guide. The tank sizing calculator tells you whether 3,000 gallons covers the draw, and the tank sizing guide covers days of supply.
Snyder's 2,650 to 3,500 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| WB70P (this tank, black water tank) | 3,000 | 90 x 125 in | 430 lb |
| 5130000C37-BLACK (black) | 3,000 | 90 x 127 in | 575 lb |
| 5130000C34 | 3,000 | 90 x 127 in | 575 lb |
| 5130000N33 | 3,000 | 90 x 127 in | 510 lb |
| 8160000N39 (1.35 SG) | 3,000 | 90 x 127 in | 610 lb |
| 8160000N43 (1.5 SG) | 3,000 | 90 x 127 in | 675 lb |
| 8160000N45 (1.9 SG) | 3,000 | 90 x 127 in | 800 lb |
| 8390000C26 (low profile) | 2,650 | 102 x 97 in | 510 lb |
| 32288 (water) | 3,500 | 96 x 125 in | 550 lb |
The 5130000 and 8160000 tanks are the liquid storage shells on this base 2 inches taller, rated for brine and chemical, the C37-BLACK the black one among them; this water tank carries less resin than any of them because water is all it is built for. The 8390000C26 lays 2,650 gallons down to 97 inches on a 102 inch base, and the 32288 is the other water tank at 3,500 gallons on a 96 inch base at this height.
Pad already poured? Send its size to 866-418-1777 or in a quote request and we will match a row to it, freight to your ZIP included.
The three openings
- Inlet: 1-1/2 inch polypropylene female NPT bulkhead fitting.
- Outlet: 2 inch polypropylene female NPT bulkhead fitting, at the base; a flexible connector between the fitting and hard pipe, and the valve supported off the pad. For a fire reserve a larger outlet is specified at order.
- Access: 18 inch threaded, vented manway, 125 inches up, reached from a short platform.
- Service limit: 120 F / 48 C.
A 2 inch outlet feeds a pressure pump or a fire pump's suction without starving it, and ten feet of water above it gives the pump a flooded suction to the last few inches. A black wall shows no level, so fit a sender read at ground level or a sight tube off the outlet, and a float switch for low level protects the pump. Where it freezes, insulate or drain the outlet valve and the first length of pipe; the body takes ice from the top down without harm.
Jobs it is bought for
Well storage for a house, a barn and a garden in full sun, a rain cistern under a large roof, stock water on a pasture, and a fire reserve of the kind the fire-water reservoir design guide describes. Several of them are the storage stage of a reuse system for roof water and condensate, per the industrial water reuse tank topology article, where the dark wall keeps the stored water from turning green.
What the carrier needs from you
The WB70P ships as LTL freight at class 400, the class light, bulky tanks take; the freight cost estimator shows it for your ZIP, and the listed price is before freight. Two people stand 430 pounds, or a forklift with long forks does it; at 90 inches across it goes outside. Fill it to the manway once, check both fittings, and keep a screen on the inlet and the vent. Tape a copy of the spec sheet inside the control panel door; the next person to touch the tank will not have the box it came in.
Freight and documents
Ships from: Philippi, WV. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries WB70P.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Snyder Industries 3000 Gallon Black Vertical Water Storage Tank video (71 seconds) with dimensions, fittings and shipping notes.
