Snyder Industries 6000 Gallon HDLPE Vertical Storage Tank with ASTM Certification for Sulfuric Acid

A full tanker of acid, with room to receive the next one

Concentrated sulfuric acid weighs nearly twice what water does and attacks the wall of an ordinary linear polyethylene tank from the inside, at the surface and in the vapor space above the liquid; Snyder's N30 resin is compounded for that service, so the tank is sized for the acid's weight and its chemistry together. Six thousand gallons takes a tanker and leaves a working reserve, which is what a plant that cannot run out wants. Acid expands more than water with temperature, so the usable volume is less than the nominal; the freeboard sizing guide works out how much, and the tank sizing calculator and the tank sizing guide size the reserve to feed rate and delivery interval. Full, it puts 95,076 pounds on a 102 inch circle at the rating: an engineered slab in full contact under the whole floor, per the concrete pad sizing guide, inside a berm sized to the tank, with the eyewash and the shower within reach of the unloading point, the empty tank strapped against wind and the manway reached from a fixed platform with a rail.

Resins on the 102 x 188 inch tank, and the sizes beside it

The N39, N33 and C137 are the same shell in lighter walls for liquids that do not attack linear polyethylene, the N39 certified at 1.35 and the N33 the black tank. The 7000000C137 holds the same 6,000 gallons on a 120 inch base at 132 inches, 56 inches shorter, for a site with floor and no height; the 1002100C126 is the 5,000 on this base, 34 inches shorter, and the 7140000C137 holds 6,900 on the ten foot base.

Neighboring size a better fit? Every row links to its own page; freight to your ZIP is quoted on each, or call 866-418-1777.

Connections

• Access: 18 inch threaded, vented manway, 188 inches up; fill through a dip tube, vent to a scrubber or outdoors, never into a room, and size the vent for a tanker's unload rate.
• Outlet: specify an acid-rated bulkhead fitting and gasket when ordering; a flanged transition, an expansion joint, and a valve supported off the slab.
• Service limit: 120 F / 48 C.

Choose a level sender rated for concentrated acid and read it at ground level so nobody climbs for a number. Acid draws water from the air and heats when it does, so the manway stays closed and the vent carries a drying trap. Never add water to the tank; dilution is done elsewhere, water first.

Delivery day at the manway

Unloading a tanker pushes air out faster than a stock manway vent can pass it; size the vent for that rate, or fill through a dedicated top bulkhead vented separately. The fill pipe runs to the floor so the acid does not free-fall and fume; on a shell this tall that is a long drop. Nobody walks away during the first fill: the slab edge and the outlet fitting are checked as the level climbs, and every delivery after that goes in the log with a date and a strength.

What it holds in practice

Sulfuric acid bulk storage for pH control at water and wastewater plants, regeneration acid at a demineralizer, pickling and plating acid at industrial scale, and any vessel of concentrated acid that has to take a tanker and keep a reserve; with water in it, a fire reserve of the kind the fire-water reservoir design guide describes, though a tank bought in this resin is bought for acid. Acid only, labeled for both inspectors at once.

Getting it to the pad

At 102 inches across and 188 inches long on the deck the 7430000N30 is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices it for your ZIP, and the listed price is before freight. A crane sets 1,800 pounds upright on the slab; unloading is a forklift job, standing it is not. Water-fill it once to the manway, hold it, then drain and dry completely before the first acid delivery; water left in an acid tank is the first mistake. Once it is full and holding, leave it alone for a day before the plumbing goes on; a settled tank is a quiet one.
