Snyder Industries 710 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

The heavy grade of the 710, and the part numbers beside it

Four part numbers share this 60 by 68 inch shell and all four are listed at 185 pounds empty, so nothing about the shape or the handling changes between them; the wall rating on each sheet is the whole difference. This sheet gives 1.9 and 11,251 pounds of maximum contents, which is the heavy grade, and it is the one to buy when the liquid on the label is denser than water at a volume this small. That combination is more common than it sounds: the dense products are usually the ones bought in small quantities, so a 710 gallon tank with a heavy wall does work that a much larger tank with a light wall cannot. One of the stablemates in this shell is listed under a reseller-prefixed part number, SII-1700200N45, alongside the plain numbers; it is in the table exactly as the sheet spells it. The shape is easy to place and that is the other half of the argument. At 68 inches the lid is at head height, reachable from a fixed step rather than a platform, and a 60 inch circle fits in a corner of a pump room, on a skid, or beside a dosing panel where nothing bigger would go. Full of water the shell holds 5,921 pounds and at the rating 11,251, all of it bearing on the whole 60 inch floor, because a rotationally molded tank carries on its floor and nothing else. That is a modest load next to the big verticals, and it is still enough to break a slab that was poured without thought, so pour it to the concrete pad sizing guide, level and in full contact, inside a berm sized to the tank where the liquid is regulated. Band it: at 185 pounds this is a tank two people can move, which means the wind can too. Black passes no light to the liquid and takes the ultraviolet that ages a white shell, and it hides the level, so the gauge is a sender. Check 710 gallons against your draw in the tank sizing calculator and take the reserve and freeboard from the tank sizing guide.

710 gallons, four part numbers

The top four rows are one tank with four walls and one listed weight; each carries the rating its own sheet gives, and this page states only its own. The last two rows are where the volume moves. The 1800000C34 holds 550 gallons on a 48 inch circle at 75 inches tall, which buys back a foot of floor diameter at the cost of height and capacity, and it is the lightest tank of the group at 110 pounds. The 5990900N42 goes slightly larger and distinctly squatter: 750 gallons on a 68 inch base at 66 inches tall, listed at 155 pounds, for a spot with width to spare and a ceiling that is closer than it looks. Buy this part number when 710 gallons is the right quantity, the liquid is dense, and a five foot circle is what the room gives you.

Not sure which one? Tell us the liquid, the site and the ceiling height at 866-418-1777, or request a written quote with freight to your ZIP.

Vent sizing on a tank a truck fills in minutes

• Vent: the listed 18 inch threaded, vented manway is the whole breathing path, and on a small tank it is the fitting most likely to be undersized in practice, because a delivery pump built for a bulk tank empties into 710 gallons very quickly. Air has to leave faster than liquid arrives. Size the vent to the pump that will actually deliver, tell the driver the tank is small, and run the vent outdoors on anything that fumes.
• Fill: a dip tube to the floor. A short tank filled fast from the top foams badly, and on a small volume the foam reaches the lid while there is still liquid on the truck.
• Headspace: leave the freeboard the sizing guide gives for expansion at the 140 F / 60 C service limit. On 710 gallons the freeboard is a small number of inches, which is exactly why it gets calculated instead of guessed.
• Outlet: the outlet field reads "1 Manway / Lid" and gives no bottom fitting size; the draw-off connection is specified at order against the named liquid, with the fitting, gasket and bolting matched to it.
• Service limit: 140 F / 60 C. Warranty: 3 year.

Five feet eight of shell gives modest suction head, so a transfer pump belongs below the take-off with a short suction run and a low-level float that stops it before it draws air. The first valve stands on its own support off the pad, with a flexible connector between the tank fitting and hard pipe, and that rule matters more on a small tank than a big one, because a light shell has less mass to resist a rigid pipe run that moves. Keep the manway closed between deliveries, write the one liquid's name on the wall, and light the band of wall above the liquid line each time the lid comes off. Where it freezes, the valve and the first pipe run get the trace heat; the shell will ice from the top down without harm.

Small volume, heavy liquid

A dosing station that meters a dense chemical a few gallons at a time, a plating or metal finishing line, a laboratory or pilot plant, a lift station with a small skid, a mobile service rig: these are the buyers of 710 gallons in a heavy wall, and the volume is chosen to match how fast the product actually gets used rather than how much a truck can bring. Whether a cross-linked shell is the right answer for that chemistry is the question the cross-linked versus high density polyethylene article addresses. Where site rules want containment rather than a berm, a double wall tank costs usable volume and the Captor double wall freeboard guide shows what is left to use at this size. Water is far inside the rating; a fire reserve, however, is a different specification, set out in the fire-water reservoir design guide.

The smallest tank in the family to ship

The 1700200N48 is listed out of Chowchilla, California at freight class 300, and at 60 by 68 inches it is the easiest tank in this group to move: it stands upright inside a standard trailer, takes little deck, and needs no permit or special handling. The freight cost estimator prices the lane to your ZIP, with the listed price before freight. Two people and a strap under the body place 185 pounds; the manway is never a lifting point. Water to the manway first, held while the base is walked, then drained and dried before the product arrives. Because a tank this small is easy to move, write the part number and the rating on it before it ever gets carried somewhere nobody remembers what it was bought for. Chalk the full-water line on the outside after the first fill; it is the level every later reading gets checked against.
