Snyder Industries 7900 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification

A tanker and a full reserve, certified, in the middle wall

A water-rated wall is for water and nothing heavier; the chemical wall is what concentrated acid needs; a 1.5 wall is the middle, sized for brine, fertilizer solution and coagulant as delivered and every water application, with margin. The certification is to ASTM D1998, which is a wall-thickness standard at heart; the HDPE tank wall thickness guide explains the sizing logic and why a wall this tall is inspected from the top, in the headspace. Full, it puts 98,829 pounds on a 120 inch circle at the rating: an engineered slab in full contact under the whole floor, per the concrete pad sizing guide, the empty tank tied down against wind and the manway served by a fixed platform with a rail. The tank sizing calculator tells you whether 7,900 gallons covers the draw, and the tank sizing guide covers days of supply.

Grades on the 120 x 177 inch tank, and the sizes beside it

The N45 is the certified 1.9 wall in this same shell at this tank's weight for ferric at strength and the heavy brines; the N40 and N42 are cross-linked polyethylene for oxidizers and the N46 another linear grade, all listed at 2,700 pounds. The 5300600 tanks hold 8,000 gallons on this base 9 inches taller at the same weight, the N43 this same certified 1.5 wall, and the 5300700C26 lays 7,650 gallons down on a 142 inch base at 122 inches for a barn roof.

Need the taller or the wider one? Every row links to its page with freight to your ZIP on each; 866-418-1777 will check the ceiling and the pad.

Access and outlet

• Access: 18 inch threaded, vented manway, 177 inches up; filled by truck through a dip tube, vented outside on anything that fumes, and size the vent for a tanker's unload rate.
• Outlet: name the liquid when ordering so the bulkhead fitting matches it; flex at the bulkhead, an expansion joint after it, and the valve braced off the slab so the fitting carries nothing.
• Service limit: 120 F / 48 C.
• Listing: ASTM certification.

The white wall shows the level in daylight; fit a sender read at ground level so nobody climbs for a number, and fit a low-level float switch so a pump never runs dry. The pump sits below the outlet so it primes by gravity; the manway stays closed; a light-sensitive liquid stays out of the sun. If winters freeze, wrap or drain the outlet valve and the first pipe run; the body takes ice from the top down without harm.

Fill day

The truck's pump outruns the manway vent, so size the vent for the unload rate or give the fill its own top bulkhead and vent line. Run the fill pipe to the floor so the liquid does not free-fall and foam. Nobody walks away during the first fill: the slab edge and the outlet fitting are checked as the level climbs, and every delivery after that goes in the log with a date and a strength.

Put to use

Coagulant, brine and fertilizer solution delivered by tanker with a full reserve, at plants and farms that need the certification on file, well storage for a community system, and a fire reserve of the kind the fire-water reservoir design guide describes. One liquid per tank, labeled.

How it ships

At 120 inches across and 177 inches long on the deck the 7370000N43 is oversize freight (NMFC 156600) on a flatbed at a lane rate; the freight cost estimator prices the move to your ZIP, and the price on this page is before freight. A crane sets 1,900 pounds upright on the slab; a forklift can take it off the deck, not raise it. One water fill to the manway, a hold, a look at the outlet fitting, and the certification goes in the project file. A strap that is checked once a season is a strap that holds; put it on the same calendar as the gutters.
