6000 Gallon Vertical Liquid Storage Tank

Where a tall six thousand goes

Fifteen feet of shell on an eight and a half foot circle suits a site that is short on ground and long on headroom: beside a well house, in a corner of a yard, in a row of tanks along a wall. It does not suit overhead lines, a low roof or a sloping pad. Tall and narrow wants a good base; use our concrete pad sizing guide before you pour. Buyers put this tank to work as a farm and ranch water reserve, as irrigation and fertilizer storage, and as the reservoir in a private fire protection system; our fire water reservoir design guide covers how a polyethylene tank fits that job and what the cold weather rules are. For water reuse and rainwater work, the industrial water reuse topology guide shows where a tank of this size sits in the train. The complete buyers guide to this tank pulls all of it together, and the tank sizing calculator and tank sizing guide settle the volume question first.

Openings and fittings

1. Outlet. A 3 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall, with a 2 inch reducer in it. Out of the box you connect 2 inch; take the reducer out and you have the full 3 inch port for a bigger valve or a faster drain. Decide which before you buy the valve. Support the valve and the first length of pipe so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top, 182 inches up. It is the fill point, the vent and the inspection opening, and on a tank this tall you reach it from a ladder or a platform, so put the tank where that is safe to do.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and the manway position for your pipe and pad layout.
4. Liquid. The 1.5 specific gravity rating covers water and most liquid fertilizers. For anything heavier Norwesco makes a 1.9 rated version of this shell, listed below. Tell us what is going in and we will confirm the material suits it.

Sizes nearby

Same shell in black, which keeps light and algae out of stored water: the 6000 gallon black vertical tank 40769. For liquids up to 1.9 specific gravity on the same footprint: the 6000 gallon heavy duty vertical tank 40233 in blue and the 6000 gallon black heavy duty vertical tank 41414. One size down on the same footprint and shorter: the 5000 gallon black vertical tank 40164B. A hundred gallons more on a wider, shorter shell: the 6100 gallon black vertical tank 40764. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships as oversize freight (Norwesco's freight class is OVS) from the nearest of Norwesco's Fairfield, Texas, Hanford, California and St. Bonifacius, Minnesota plants, 182 by 102 by 102 inches lying down on the truck and 1275 lb. It travels on an open trailer, so plan on a forklift, a loader with forks or a crew with straps, and a clear route from the truck to the pad. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 40226 on the bill of lading, look over the shell for transit damage before you sign, stand it on the finished pad, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
